Table 3. M6100 Switch Chassis technical specifications (continued)
Data center technology
MAC address entries
Performance
Interface
NETGEAR M6100 Switch Chassis
Priority flow control
•
Data center bridging
•
Enhanced transmission selection
•
FIP snooping
•
XCM8944/44F/48/24X = 32K entries
•
Forwarding Modes: Store-and-Forward
•
Network latency:
•
2.8 μs for 64-byte frames for 1000 Mbps to 1000 Mbps
-
transmission
1.5 μs for 64-byte frames for 10G to 10G transmission
-
XCM8944
40 RJ-45 port for 10/100/1000M
•
40 PoE+ or UPOE depned on install XCM89P or XCM89UP PoE
•
Daughter Card
2 RJ-45 port for 100/1000M/10G
-
2 SFP+ port for 1G/10G
-
1 RJ-45 OOB port for 10/100/1000M
-
1 USB 2.0 host port
-
1 RJ-45 console port
-
1 mini-USB console port
-
XCM8948
48 RJ-45 port for 10/100/1000M
•
48 PoE+ or UPOE depned on install XCM89P or XCM89UP PoE
•
Daughter Card
1 RJ-45 OOB port for 10/100/1000M
-
1 USB 2.0 host port
-
1 RJ-45 console port
-
1 mini-USB console port
-
XCM8944F
40 SFP port for 100/1000M
•
2 RJ-45 port for 100/1000M/10G
•
2 SFP+ port for 1G/10G
•
1 RJ-45 OOB port for 10/100/1000M
•
1 USB 2.0 host port
•
1 RJ-45 console port
•
1 mini-USB console port
•
XCM8924X
8 RJ-45 port for 100/1000M/10G
•
8 SFP+ port for 1G/10G
•
16 SFP+ / RJ45 10G Combo port
•
1 RJ-45 OOB port for 10/100/1000M
•
1 USB 2.0 host port
•
1 RJ-45 console port
•
1 mini-USB console port
•
Technical Specifications
