Step 4:
By turning the helically grooved spindle, move the right guide bar to the value of
wall.
WARNING!
Step 5:
Mount the winding chain (1), the reel remains
unchanged with the inlet bend pointing down.
Tighten the winding chain (1).
24
Thereby the spindle must be turned in the direction of winding (counter-
clockwise, see sketch).
At this point, the winding carriage moves from the reversing point to the left
(direction A).
1
Betriebsanleitung für Smart RAIN
"0"
towards the inner reel side
