W&T
The pinout for the individual ports can be found in the follo-
wing tables.
RS232 input Port A and B with DCE pin functions:
Pin#
Function
1
always "on"
2
data out
3
data in
4
handshake in
5
signal GND
6
handshake out
7
not connected
8
handshake out
9
always "off"
RS232 output Port C with DTE pin functions:
Pin#
Function
1
not connected
2
data in
3
data out
4
handshake out
5
signal GND
6
not connected
7
always "on"
8
handshake in
9
not connected
8
RS232 Multi Computer Adapter
Signal
Direction
DCD
output
RxD
output
TxD
input
DTR
input
GND
GND
DSR
output
RTS
input
CTS
output
RI
output
Signal
Direction
DCD
input
RxD
input
TxD
output
DTR
output
GND
GND
DSR
input
RTS
output
CTS
input
RI
input
