2.2 Technical features of the video Terminal
Supply tension
Display
Keyboard
Adjustments
Case
Mounting
Casing protection level (IP)
Operating temperature range
Range of transport and storage
temperatures
Dimensions
Weight
2.3 Technical features of the Supply control unit
Supply tension
Generated power tensions/power
capability
Case
Mounting
Casing protection level (IP)
Operating temperature range
Range of transport and storage
temperatures
Dimensions
Weight
2.4 Technical features of the Video connection box
Main input – output
12,0 ... 14,3 V DC (stabilized)
3.5" LCD, TFT, resolution: 320 x RGB x 240;
Display Up/down/right/left visibility angle: 10/35/50/50
TOUCH type,4 keys Backlit on touch
Permanent RED signaling of the VOLUME key if the
Terminal is turned off.
Audio communication volume:
MAXIMUM LEVEL – MEDIUM LEVEL – TURNED OFF
- Image characteristics: luminosity, chrominance, video
impedance adjustment
ABS Glass screen, 3 mm thick
Surface
IP31
0°C ... + 45°C
- 33°C ... + 55°C
212 x 96 x 30 mm
0,4 kg
230V±10%/50Hz
+14V - GND : +14V DC (stabilised)/2A DC
+ Uv - GND : +14V DC
Ucam - GND : +14V DC
Fireproof ABS
-On DIN rail: TH 35 x 15 or 35 x 7,5 in compliance
with DIN46277-3, EN50022, IEC60715
-Surface: with A3,5 x 32 plastic screws and ø 6 mm
pins
IP31
0°C ... + 45°C
- 33°C ... + 55°C
130 x 141 x 73 mm
0,4 kg
1
(stabilised )/0.5A DC
(stabilised )/0.2A DC
3/17
