English
SYMBOLS
mΩ unit of resistance
V
unit of voltage
HOLD function activated: the result remains held on the display
HOLD
unit
COMP
comparator function activated
low battery level indicator
warning beep activated
DATA R
activation of manual memory Read mode
DATA M
activation of manual Memory storage mode
data logger mode in use; this symbol flashes each time a sample
M
is stored.
sets parameters of data logger mode: time interval between 2
INTV
samples (1~255s)
COMP.SET
activation of comparator parameter settings
HIGH
high resistance and voltage limits of the comparator
LOW
low resistance limit of the comparator
LEDS
These are lit when the measurement result is compared to a comparator.
PASS
(green LED)
WARNING
(yellow LED)
FAIL
(red LED)
indicates that the battery tested is OK (lies within the limits of
the comparator).
indicates that the battery tested is in an intermediate condition
(deteriorating).
indicates that the battery tested is deteriorated
