Mainframe HM8001-
I Compartment for 2 Modules
I Rear Panel Signal Interconnection (Option HO801)
I Independent Voltage Supplies
I Multi-Stack Possibility with Footrests
The Mainframe HM8001-2 with its
incorporeted power supplies is the basis
for the HAMEG Modular System 8000.It
accommodates any two System 8000
modules. With a total of 8 completely in-
dependent and floating voltages, all
module types can be powered individually.
The maximum total power output of each
mainframe is 36Watts. Loads which draw
exessive power will activate the tranc-
former's safety shut-down protection until
removed. The 8000 series modules use
less then 11Watts of power each under
normal circumstances, with the exeption
of the Power Supply HM8040, which
requires 25Watts by itself and should not
be used in conjuction with another HM8040
Specification
Reference Temperature: 23°C ± 1°C
General
Mainframe with power supply accomodates
any 2 modules.
4 BNC connectors on rear panel for external
interconnection to each module compartment
(Option HO801)
Module Supply Voltages
2x8V , max. 0,5A each
AC,
2x5V , max. 1A each
DC
4x20V , max. 0,5A each
DC
Voltages between 5V and 20V are
programmbale from each module.
Polarity: Optional
Power Consumption per Module: max 25Watt
All DC voltages are electronicaly stabilized,
2
module in it's mainframe. In case the
HM8001-2 is equipped with the option
HO801, four BNC terminals are provided on
the rear side of the HM8001-2 which allow
signals from or to the module to be
interfaced.
The mechanical strength of the mainframe
allows to store up to 5 units on top of each
other. A great number of measuring options
can thereby be combined in very limited
space. Each Mainframe has easily removable
foot rests on its top which keep stacked on
each other from sliding. The Mainframe of
the Modular System 8000 can also be
stacked with any other HAMEG instru-
ments, such as Oscilloscope and System
8100 Instruments.
floating and short circuit proof.
AC test voltage to chasis: 500V
Genaral Information
Power switch on front panel between the
two modules.
Line voltage: 115/230V~
Permissible Line Fluctation: ±10%
Line Frequency Range: 50-60HZ
Power Consumption: max 110Watt
Protective System: Safety Class I(IEC 348)
Case (mm): W 285, H 75, D 365
Weight: approx. 4kg
Color: techno-braon
2 tils stands
4 footrests for stacking
