16.6.3 UL-sikringer og ledertværsnit til net og motor
Typisk
akseleffekt P2
Bussmann Bussmann
RK1
[kW]
1 x 200-240 V
1,1 KTN-R20
1,5 KTN-R30
2,2 KTN-R40
3 KTN-R40
3,7 KTN-R60
5,5 –
7,5 –
3 x 200-240 V
0,75 KTN-R10 JKS-10
1,1 KTN-R20 JKS-20
1,5 KTN-R20 JKS-20
2,2 KTN-R20 JKS-20
3 KTN-R30 JKS-30
3,7 KTN-R30 JKS-30
5,5 KTN-R50 JKS-50
7,5 KTN-R50 JKS-60
11 KTN-R60 JKS-60
15 KTN-R80 JKS-80
18,5 KTN-R125 JKS-150
22 KTN-R125 JKS-150
30 FWX-150
37 FWX-200
45 FWX-250
3 x 380-500 V
0,55 KTS-R10 JKS-10
0,75 KTS-R10 JKS-10
1,1 KTS-R10 JKS-10
1,5 KTS-R10 JKS-10
2,2 KTS-R20 JKS-20
3 KTS-R20 JKS-20
4 KTS-R20 JKS-20
5,5 KTS-R30 JKS-30
7,5 KTS-R30 JKS-30
11 KTS-R40 JKS-40
15 KTS-R40 JKS-40
18,5 KTS-R50 JKS-50
22 KTS-R60 JKS-60
30 KTS-R80 JKS-80
37 KTS-R100 JKS-100
45 KTS-R125 JKS-150
55 KTS-R150 JKS-150
75 FWH-220
90 FWH-250
3 x 525-600 V
0,75 KTS-R10 JKS-10
1,1 KTS-R10 JKS-10
1,5 KTS-R10 JKS-10
2,2 KTS-R20 JKS-20
3 KTS-R20 JKS-20
4 KTS-R20 JKS-20
5,5 KTS-R30 JKS-30
7,5 KTS-R30 JKS-30
3 x 525-690 V
11 KTS-R-25 JKS-25
15 KTS-R-30 JKS-30
18,5 KTS-R-45 JKS-45
22 KTS-R-45 JKS-45
30 KTS-R-60 JKS-60
37 KTS-R-80 JKS-80
45 KTS-R-90 JKS-90
55 KTS-R-100 JKS-100
75 KTS-R125 JKS-125
90 KTS-R150 JKS-150
1)
Skærmet motorkabel, uskærmet forsyningskabel.
126
Sikringstype
Bussmann SIBA
J T RK1
– – –
– – –
– – –
– – –
– – –
– – –
– – –
JJN-10 5017906-010
JJN-20 5017906-020
JJN-20 5017906-020
JJN-20 5017906-020
JJN-30 5012406-032
JJN-30 5012406-032
JJN-50 5012406-050
JJN-60 5012406-050
JJN-60 5014006-063
JJN-80 5014006-080
JJN-125 2028220-125
JJN-125 2028220-125
– – 2028220-150
– – 2028220-200
– – 2028220-250
JJS-10 5017906-010
JJS-10 5017906-010
JJS-10 5017906-010
JJS-10 5017906-010
JJS-20 5017906-020
JJS-20 5017906-020
JJS-20 5017906-020
JJS-30 5012406-032
JJS-30 5012406-032
JJS-40 5014006-040
JJS-40 5014006-040
JJS-50 5014006-050
JJS-60 5014006-063
JJS-80 2028220-100
JJS-100 2028220-125
JJS-150 2028220-125
JJS-150 2028220-160
– – 2028220-200
– – 2028220-250
JJS-10 5017906-010
JJS-10 5017906-010
JJS-10 5017906-010
JJS-20 5017906-020
JJS-20 5017906-020
JJS-20 5017906-020
JJS-30 5012406-032
JJS-30 5012406-032
JJS-25 5017906-025
JJS-30 5017906-030
JJS-45 5014006-050
JJS-45 5014006-050
JJS-60 5014006-063
JJS-80 5014006-080
JJS-90 5014006-100
JJS-100 5014006-100
JJS-125 2028220-125
JJS-150 2028220-150
Littel Fuse Ferraz-Shawmut Ferraz-Shawmut
RK1 CC
– –
– –
– –
– –
– –
– –
– –
KTN-R10 ATM-R10
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R30 ATM-R30
KTN-R30 ATM-R30
KLN-R50 –
KLN-R60 –
KLN-R60 A2K-60R
KLN-R80 A2K-80R
KLN-R125 A2K-125R
KLN-R125 A2K-125R
L25S-150 A25X-150
L25S-200 A25X-200
L25S-250 A25X-250
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R30 ATM-R30
KTN-R30 ATM-R30
KLS-R40 –
KLS-R40 –
KLS-R50 –
KLS-R60 –
KLS-R80 –
KLS-R100 –
KLS-R125 –
KLS-R150 –
L50S-225 –
L50S-250 –
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R10 ATM-R10
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R20 ATM-R20
KTN-R30 ATM-R30
KTN-R30 ATM-R30
KLSR025 HST25
KLSR030 HST30
KLSR045 HST45
KLSR045 HST45
KLSR060 HST60
KLSR075 HST80
KLSR090 HST90
KLSR100 HST100
KLS-125 HST125
KLS-150 HST150
2)
American Wire Gauge.
Maks.
1)
ledertværsnit
RK1 2)
[AWG]
– 10
– 7
– 7
– 7
– 7
– 7
– 2
A2K-10R 10
A2K-20R 10
A2K-20R 10
A2K-20R 10
A2K-30R 10
A2K-30R 10
A2K-50R 7
A2K-50R 7
A2K-60R 7
A2K-80R 2
A2K-125R 1/0
A2K-125R 1/0
A25X-150 1/0
A25X-200 4/0
A25X-250 250 MCM
A2K-10R 10
A2K-10R 10
A2K-10R 10
A2K-10R 10
A2K-20R 10
A2K-20R 10
A2K-20R 10
A2K-30R 10
A2K-30R 10
A6K-40R 7
A6K-40R 7
A6K-50R 7
A6K-60R 2
A6K-80R 2
A6K-100R 1/0
A6K-125R 1/0
A6K-150R 1/0
A50-P225 4/0
A50-P250 250 MCM
A2K-10R 10
A2K-10R 10
A2K-10R 10
A2K-20R 10
A2K-20R 10
A2K-20R 10
A2K-30R 10
A2K-30R 10
A6K-25R 1/0
A6K-30R 1/0
A6K-45R 1/0
A6K-45R 1/0
A6K-60R 1/0
A6K-80R 1/0
A6K-90R 1/0
A6K-100R 1/0
A6K-125R 1/0
A6K-150R 1/0
