ASSEMBLY
PREPARATIONS
1. Before assembly make sure there is enough space.
2. Use the recommended tools.
3. Before assembly check if there are all the parts in the box.
It is recommended that product should be assembled by at least two people
to avoid injuries.
ASSEMBLY INSTRUCTIONS (Drawings – p. 44-45)
ATTENTION! Do not connect the device to the power source until you finish
the assembly.
STEP 1. Pull the treadmill out of the carton and place it on a flat, level
surface.
STEP 2. Raise side columns, position them in the correct position. Put the
counter console on columns.
FOLDING AND TRANSPORT OF THE TREADMILL
Don't try to move the treadmill if it's not folded and locked. Make sure that
the plug is disconnected from power supply.
To fold the treadmill, the running area must be raised with both hands until
a gentle signal is heard, informing that the treadmill has been correctly
locked in vertical position.
To assemble the treadmill, the coloured element on the piston situated
under the treadmill belt should be pressed with one foot, which will release
the lock. Next, the treadmill belt should be gently pulled down and the
operator should back 2 metres away from the treadmill as it will unfold
MAINTANCE
Caution: before cleaning / lubrication you must take out the power plug from
a socket.
For cleaning the exercise machine, do not use any abrasive detergents.
Use a soft, damp cloth to remove dirt and dust.
The monitor (power supply dome) should be cleaned only with a dry cloth.
The equipment should be stored in dry places in order to protect it from any
moisture and corrosion.
Use a soft, damp cloth to wipe off the edges of the treadmill belt, and the
space between the treadmill belt and the frame edges. Clean the edge of
the belt on its bottom side also. Clean the upper part of the belt with a brush
Belt tension adjustment
Belt Tension Adjustment-It is very important for joggers and runners in
order to provide a smooth, steady running surface. Adjustment must be
made from the right and left rear roller in order to adjust tension with the
Hexagonal Wrench provided in the parts package. The adjustment bolt is
located at the end of the rails as noted in diagram below.
Note: Adjustment is thru the small holes on the end caps.
Belt tracking adjustment (picture, p. 46)
This treadmill is designed to keep the belt reasonably centred while in use.
It is normal for some belts to drift near one side while the belt is running
with no one on it. After a few minutes of use, the belt should have a
tendency to centre itself. If during use, the belt continues to move toward
one side, adjustments are necessary. The procedures are as below:
▲ First set speed at lowest position.
▲ Second check the belt shifts to which side.
How to check the running mat for proper lubrication (picture, p. 46)
 Disconnect the main power supply.
 Fold the treadmill up into the storage position.
Belt/deck/roller lubrication
The mat/deck friction may play a major role in the function and life of your
treadmill and that is why we recommend you constantly lubricate this
friction point to prolong the life time of your treadmill.
You should apply the lubrication after approximately the first 20 hours of
operation. We recommend lubrication of the deck every 30 days.
See below procedures for lubricating:

Use a soft, dry cloth to wipe the area between the belt and deck.
Most of the assembly equipment listed here has been packed separately,
but some elements come preassembled in certain assembly parts. If it is
required, dissassemble them and assemble again.
Read the instructions of all assembly steps and familiarize with all the
devices installed.
STEP 3. Screw the side columns to the lower part – that project from the
main frame with the use of fi8 washers and M8x15 and M8x45 screws and
M8 nuts. The counter console also connects to the side columns with the
use of fi8 washers and M8x15 and M8x45 screws and M8 nuts.
STEP 4. Use M4x13 screws in order to secure side covers of the treadmill's
base..
automatically. Please refer to the drawing 1 (p. 46).
ATTENTION: Folded treadmill cannot be operated and utilized. Stop the
treadmill belt before folding the equipment. Folded treadmill should be
disconnected from power supply. Don't start the treadmill when it's folded.
To move the treadmill, raise it gently onto the rear transport rolls and move
it to the desired location, holding on both sides.
ATTENTION: Before transporting the treadmill make sure that it is
disconnected from power supply. The device should always be transported
by two persons..
and soap water once a month.
NOTE: Before you start using the treadmill again, wait until the equipment
is completely dry.
Vacuum under the equipment at least once a month to prevent dust from
accumulating.
Once a year, it is recommended to remove the black cover of the engine in
order to remove any dust that may accumulate there.
NOTE: The level of equipment operational safety can be maintained only
by regular inspections checking for any damage and wear.
Connecting elements are the most vulnerable to any wear..
TREADMILL BELT
Tighten the rear roller only enough to prevent slippage at the front roller.
Turn both the right and left bolt clockwise reasonably and inspect for proper
tension. When an adjustment is made to the belt tension, you must also
make a tracking adjustment to compensate for the change in belt tension.
DO NOT OVERTIGHTEN - Over tightening will cause belt damage and
premature bearing failure.
If the belt shifts to right, tighten the right bolt and loosen the left bolt by
using 6mm Hexagonal Wrench, until the belt is centered itself; if belt shifts
to left, tighten the left bolt and loosen the right bolt by using 6mm Hexagonal
Wrench, until the belt is centered. When adjusting the belt using the 6 mm
Hexagonal Wrenches, it is important to adjust the belt in half turn
increments. Over adjusting the belt can cause damage to the mat.
 Feel the back surface of the running mat.

Spread lubricant onto the inside surface of belt and deck evenly (make
sure the machine is turned off and power is disconnected).

Periodically lubricate the front and rear rollers to keep them at their
peak performance.
If the treadmill belt/deck/roller is kept reasonably clean it is possible to
expect over 120 hours before additional re-lubing is necessary.
7
