Instructions for use
Point of impact to the left of the target dot:
(weapon shooting left) – turn the adjusting screw in the R direction
Point of impact to the right of the target dot:
(weapon shooting right) – turn the adjusting screw away from the R direction
After each adjustment or before each shot, retighten the locking screw for
target dot locking (Fig. 1/D).
Note: If the adjusting or locking screw is completely unscrewed the interior of
the Compact Point is exposed to environmental influences.
Attaching the protective case
Position the front end of the protective case in the provided grooves (Fig. 5/P),
then with the rear end push the protective case onto the Compact Point.
To lock the protective case in position, it must be fixed to the Compact Point
with the screws provided (Fig. 6/Q). Using the multi-function key.
Care and maintenance
Your Carl Zeiss Compact Point requires no special maintenance.
Do not wipe coarse dirt particles (e.g. sand) from the lens, rather blow them
away or remove with a camel hair brush! Fingerprints can attack the lens
surface after some time. Breathing on the lens surface and wiping off with a
clean optical cleaning cloth is the simplest way to clean.
Protect the device as much as possible against the action of grease and
oil-containing materials. Dirt and fingerprints can be eliminated easily with
pure alcohol (no acetone) and a clean cloth. The battery compartment and the
battery compartment cover should always be kept clean and dry.
Caution!
Never look into the sun or laser light sources with the Compact Point.
This can result in serious damage to the eyes.
