Instructions for use
Operation
Press the function button (Fig. 2/F) once briefly to switch on the Compact
Point.
The brightness of the target dot can be adjusted incrementally to 5 levels by
repeatedly pressing the function button. With each press of the button the red
dot is adjusted sequentially by one intensity level higher or lower in an infinite
loop.
The Compact Point is switched off by holding down the function button for
two seconds. The last intensity level selected is stored in memory and activat-
ed when the device is switched on again.
Installation of Compact Point "Standard" for Picatinny and Weaver rails
Installation of the Compact Point "Standard" is done on a rail which corre-
sponds to the design of the Picatinny rail (MIL-STD 1913) or Weaver rail.
Clamp Compact Point "Standard"
The Compact Point is fitted with a clamp using a fixing plate and M3 hexagon
socket screw.
Installing the Compact Point "Standard"
Place the Compact Point against the rail so that the front housing pin
(Fig. 2/G) fits in a transverse groove on the rail.
Place the Compact Point in the direction of the arrow and tighten the M3
hexagon socket screw (Fig. 1/E) using the special wrench (Fig. 3).
Removing Compact Point "Standard" from the rail
Follow the above directions in the reverse order – Loosen hexagon socket
screw and remove the Compact Point in the opposite direction to the arrow
(Fig. 6).
