Nederlands
Overzicht basisstation
[11] Afdekking van het basisstation
[12] Oplaadstation headset
[13] Schakelaar voor kiestoon
[14] LCD-scherm
[15] Aansluiting telefoonkabel
[16] Hoornpoort
[17] Aansluiting voedingsadapter
[18] USB-poort
[19] Online indicator poort (OLI)
[20] AUX poort voor GN 1000
[21] Koppelingsknop (Pairing)
[22] Instelling LCD-scherm
[23] Oplaadtoren
[24] USB-Modus functie (met indicator)
[25] Mute indicator
[26] Batterij indicator (vier dioden)
[27] Telefoon-Modus functie (met indicator)
[28] Voedingskabel
[29] USB-verbindingskabel
[31] Telefoonkabel
11
2
Overzicht basisstation
Deutsch
Übersicht Basisstation
[11] Abdeckung der Basisstation
[12] Headset-Ladeschale
[13] Telefon-Setup-Schalter für klares
Freizeichen
[14] LCD-Display
[15] Telefonkabel-buchse
[16]Telefonhörer-Kabelbuchse
[17] Buchse für Netzteil
[18] Buchse für USB-Kabel
[19] Buchse für Online-Anzeige (OLI)
[20] AUX-Buchse
[21] Abgleichtaste (Pairing)
[22] LCD-Display-Regelung
[23] Ladestation/Basisstation
[24] Umschalter PC-Modus (inkl. Anzeige)
[25] Online-Anzeige für Stummschaltung
[26] Akkuanzeige (4 Dioden)
[27] Umschalter Telefonmodus (inkl. Anzeige)
[28] Netzteiladapter
[29] USB-Kabel
[30] Anschlusskabel
12
13
14
15
16
17
18
30
Übersicht Basisstation
Italiano
Presentazione base
[11] Coperchio della base
[12] Supporto di ricarica della cuffia
[13] Tasto segnale di linea libera
[14] Display LCD
[15] Presa telefono
[16] Presa microtelefono
[17] Presa adattatore di alimentazione C/A
[18] Porta USB
[19] Porta indicatore on-line (OLI)
[20] Porta AUX
[21] Pulsante di pairing
[22] Controllo del display LCD
[23] Torre di ricarica
[24] Pulsante modalità USB (con indicatore)
[25] Indicatore esclusione microfono
[26] Indicatore batteria (4 diodi)
[27] Pulsante modalità telefono
(con indicatore)
[28] Cavo di alimentazione C/A
[29] Cavo USB
[30] Cavo telefonico
22
21
24
19
20
28
29
Presentazione base
23
27
25
26
