Operating Instructions
Time Duration
Z0
0,5.s
Z1 2.s
Z2 0,3.s
Z3
3.s
Z4 60.s
Z5 0,1.s
Z6 120.s
Z7
Z8 1.s
Z9 0,1.s
Z10 0,05.s
Fault
No.reaction.to.pressing.the.button,.
+UB.lamp.is.not.lit
No.immediate.reaction.to.pressing.the.button,
LED.+UB.lit.up
No.auxiliary.power.at.terminals.A-/B+
(24.V.DC./.300.mA)
Note
Please also observe the indication of faults and errors by the LED's on the pc board of the basic control
unit S80 and ELS Professional Card.
40
Overview of control times
Description
Stopping.time.for.opposite.UP.command.due.to.UP.button.or.photoelectric.barrier
Clearance.time.when.moving.clear.of.an.obstacle
Stopping.time.for.opposite.UP.command.due.to.safety.edge
Early.warning.time
Closing.time.if.automatic.closing.is.activated;.adjustable.from.2.-.240.s.when.time.module.is.
mounted
Reversing.time.to.relieve.the.safety.edge
Time.the.yard.light.remains.on
Is.programmed.automatically
Waiting.time.for.safety.edge.signal.in.the.bottom.end.position.for.testing.the.safety.edge
Inhibition.detection.time
Jogging.mode.for.setting.end.positions
What do you do if...?
Possible cause and remedy
•. Check.supply.voltage.(terminals.L3/L2/L1/N.(MAINS)).
•. Check.miniature.fuse.F1.(400.mA,.slow.blow).
•. Check.EMERGENCY.OFF.button.(terminals.A2/B2.(EMERGENCY.OFF)).
•. Check.safety.circuit.of.the.drive.(terminals.E1 ... E11,.emergency.hand.
crank.(chain),.drive.temperature).
•. Check.terminals.A3/B4.(STOP),.A5/B5.(STOP-AUF),.A7/B7.(LS).and.
A10/B10. (SCHLAFFSEIL/ÜL).. If. these. pairs. of. terminals. are. not. as-
signed,.they.must.be.jumpered.
•. Early.warning.is.active
. Check.the.setting.of.the.DIP.switch.1..and.1.6.
•. Check. whether. you. are. using. the. correct. control. card. for. the. drive:.
MLS.Basic.Card/MLS.Professional.Card.for.drives.with.mechanical.limit.
switching,.ELS.Basic.Card/ELS.Professional.Card.for.drives.with.elec-
tronic.limit.switching.
•. Check.miniature.fuse.F2.(315.mA,.slow.blow).
