6. Symbols of the Display

-
-
-
-
- AUTO
-
- H
Ω
-
Hz
-
- A
- V
- NCV
- OL / - - - - Overload indicator
- Sidedisplay (Small numbers)
This device does not use all the symbols shown in the image.
AC voltage / current
DC voltage / current
Battery low
Operation indicator / Auto power off
Automatic range selection active
Audible continuity test active
Data hold
Resistance measurement
Frequency measurement
DC current measurement / AC Current measurement
DC Voltage measurement / AC Voltage measurement
Non Contact Voltage tester (NCV)
