Technische Spezifikationen; Voiceprozessor - Junger Audio v 01 Bedienungsanleitung

TECHNISCHE
SPEZIFIKATIONEN
input:
input impedance:
max. input level:
gain (mic gain + gain):
frequency response:
CMRR:
THD + N:
equiv. inp. noise:
output:
output impedance:
output level:
frequ. resp.:
with calibration
THD:
dynamic range:
noise :
input:
input impedance:
inp. level:
CMRR:
a/d converter:
dynamic range:
THD + N:
frequency response:
format :
input:
input sample rate:
Bedienungsanleitung VAMP1, Kapitel 9 -Technische Spezifikationen- Seite 9-
1
electronical. floating balanced
5 kOhm
+6 dBu, wenn mic gain 0...+20dB
-25 dBu, wenn mic gain > +20dB
0 ...+90 dB, in 1 dB Schritten
40 Hz ... 15 kHz
-95 dB @ 50 Hz
-85 dB @ 15kHz
-102 dB @ max. inp. Level
@ 200 Ohm, mic gain > +20dB
RMS: -126 dBFS
A-wght: -128 dBFS
QP-CCIR : -113 dBFS
electronical balanced
50 Ohm
+11...+22 dBu adjustable, @ 0 dBFS
20 Hz ... 20 kHz , (-0.5 dB)
0 dBFS = +15 dBu
<0.005 %
93 dB
-78 dBu (RMS)
-68 dBu (QP-CCIR)
electronical balanced
10 kOhm
+10...+20 dBu adjustable, @ 0 dBFS
-80 dB @ 50 Hz
18 bit oversampling
92 dB
-83 dBFS @ max. inp. Level
-92 dBFS @ -60 dB
20 Hz ...20 kHz, ( -0.5 dB)
AES/EBU, S/PDIF, EIAJ-340
XLR, balanced , 110 Ohm, 2 Vpp
RCA, unbal. , 75 Ohm, 0.5 Vpp
30 .. 50 kHz
asynchronous sample rate conversion, 16 bit
dynamic range: 94 dB
(not transparent for C- or U-bits)

9. TECHNISCHE SPEZIFIKATIONEN

9
9.1
VOICE
PROZESSOR
mic in
mic out
analogue source
digital source
