English
CH AR G E ST AT U S
Boost
Equalize
Compensate
Float
Jogging
Reverse polarisation
or no battery present
Battery voltage to low
14 hours limit
Temperature sensor
Battery sulphated
Temp.sensor error
Consult "Trouble shooting" for the error messages
CO N N ECT IN G A B AT T ERY S E P AR AT O R
You can charge/maintain two or three battery sets simultaneously by using a battery
separator. It is important to connect the D+ connector of the charger. If the D+ connector is
not connected then the system will not work. Connect the D+ connection on the charger
with the D+ connection on the battery separator by means of a thin cable (+/- 1.5mmq). In
addition, mount a diode between the D+ of the dynamo and the D+ battery separator.
We advise to use the low-loss DB 180 (2 outputs) or the DB 270 (3 outputs).
T EM PER AT UR E CO M P EN S AT IO N
The optional temperature sensor BTC 100 measures the temperature of the battery during
the entire charging process. Depending on the temperature measured the end voltage is
compensated. This compensation must be activated. See the chapter 'Setting the charge
program'.
LCD M O NIT O R
If the optional LCD monitor PCM 100 is connected, it's possible to follow the charging
process remotely. The monitor displays details such as the battery voltage, charging
current, charging phase and any errors which may occur.
23
LED yellow
LED
red
lights
X
X
LED green
blinks lights
X
X
Error
display
blinks
X
1 1 1 1
2 2 2 2
3 3 3 3
4 4 4 4
5 5 5 5
6 6 6 6
