Scart cable
Use Scart adapter cable
(All illustrated cables are not supplied)
You can supply the TV sound to the stereo system (A)
via either the analogue Cinch audio output or the digital
audio output (coaxial) (B).
(A)
Use an RCA audio cable to connect the analogue audio output
of your TV set to the left and right stereo audio input connectors.
(Please consult your hi-fi intructions for details). When connecting,
make sure to match the connectors colour codes red to red and
white to white.
If you have a digital sound amplifier/deoder (B), use a coaxial cable
to connect the digital audio output (coaxial) of your TV set to the
corresponding digital audio input of your digital sound system.
(Please consult your digital audio system's instructions for details)TV Back
(All illustrated cables are not supplied)
12
Video recorder
AV cable Video camera
LED 2600 66 cm (26") LED BLU-TV
Audio cable
YPbPr cable
(All illustrated cables are not supplied)
When using the SCART cable
When using the HDMI cable
When using the YPbPr cable
lect YPbPr as input source
HDMI to HDMI
SCART
