4.7.1 Parameter bei DA1
CANOpen
Para-
Bezeichnung
Index
meter
[hex]
2065
P1-01
f-max
2066
P1-02
f-min
2067
P1-03
t-acc
2068
P1-04
t-dec
2069
P1-05
Stopp Modus
206A
P1-06
Energieoptimierung
206B
P1-07
Motor Nennspannung
206C
P1-08
Motor Nennstrom
206D
P1-09
Motor Nennfrequenz
206E
P1-10
Motor Nenndrehzahl
206F
P1-11
U-Boost
2070
P1-12
Lokale Prozessdaten Quelle
2071
P1-13
DI Konfiguration Auswahl
2072
P1-14
Kennwort
20C9
P2-01
f-Fix1
20CA
P2-02
f-Fix2
20CB
P2-03
f-Fix3
20CC
P2-04
f-Fix4
20CD
P2-05
f-Fix5
20CE
P2-06
f-Fix6
20CF
P2-07
f-Fix7
20D0
P2-08
f-Fix8
20D1
P2-09
f-Skip1
20D2
P2-10
f-SkipBand1
20D3
P2-11
ADO1 Funktion & Modus
20D4
P2-12
AO1 SignalFormat
Tabelle 21: Parameter bei DA1
Zugriff
rw/
RUN/
ro
STOP
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
STOP
rw
STOP
rw
STOP
rw
RUN
rw
STOP
rw
STOP
rw
STOP
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
rw
RUN
CANopen für DA1, DC1, DE11 09/16 MN040019DE www.eaton.com
4 CANopen Kommunikationseinstellungen
Skalierung
Wertebereich
3000 ≙ 50.0Hz
P1-02 - 5 x P1-09
(max.: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0Hz
0.0 Hz - P1-01
300 ≙ 30.0s
0.00 s - 6000 s
300 ≙ 30.0s
0.00 s - 6000 s
0 - 4
0 - 1
230 ≙ 230 V
0 - U
e
1 ≙ 0.1A
0.1 I
- I
e
e
50 ≙ 50Hz
10 Hz - 500 Hz
1500 ≙ 1500rpm
0 / 200 rpm - 30000 rpm
-1 ≙ Auto
0 - Auto / 0 - 30.0 % P1-07
0 ≙ disabled
1 ≙ 0.1%
0 - 13
0 - 21
0 - 30000
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0 Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
3000 ≙ 50.0Hz
P1-02 (min: 0 Hz / 0 rpm) - P1-01
(max: 500.0 Hz / 30000 rpm)
0 - 11
0 - 5
4.7 Parameter
Daten-
format
U16
U16
U16
U16
U16
WORD
U16
U16
U16
U16
S16
U16
U16
U16
U16
U16
U16
U16
U16
U16
U16
U16
U16
U16
U16
U16
41
