HDFS100 511
CONNECTION & OPERATION
Connection
Step 1: Use HDMI cable to connect the HDMI IN of HDFS100 Transmitter to a
Source device (Satellite receiver, CATV STB, BD player, PS3, XBox...),
if you want to watch the source program on the same time , you can
use another HDMI cable connected the HDMI OUT to display (HDTV).
Step 2: Use HDMI cable to connect the HDMI OUT of HDFS100 receiver to a
display device (HDTV, Projector...)
Step 3: Connect the IR emitter to the HDFS100 Transmitter. And then place the
emitter probe in front of the source device's IR receiver. Connect the IR
receiver to the HDFS100 Receiver. And then place the receiver probe in
front. (If you do not need the IR extending function, please skip step 3)
Step 4: Connect a DC 5V/1A power adaptor to the Power Jack (MicroUSB) of
HDFS100 Transmitter.
Step 5: Connect another DC 5V/1A power adaptor to the Power Jack (Micro
USB) of HDFS100 Receiver.
Step 6: Connection Finish. If you can not get image on your display device,
please pairing the TX and RX first.(Press the MODE key of RX box and
then press the MODE key of TX box).

Operation

A. Installation
1. Make sure your input AC voltage conforms to the adaptor specifications.
2. Only use the power adaptor provided with the HDFS100. If you use your
own adaptor, make sure the power output is 5V DC, 1A centre positive.
3. With direct line-of-sight, the maximum range of A/V signal transmission
can reach up to about 100 feet, and this distance would be shortened by
obstacles or walls placed between transmitter and receiver. (The optimum
indoor range is under 30M)
4. To ensure good infrared remote control operation aim your remote control
at the IR Probe of the HDFS100 and press the buttons firmly. (With some
remote controls it may be necessary to press and hold each button for
about a second). The working angle of the IR Probe is +/- 15 degrees.
5. The remote controller has to be used within the distance of (from remote
control to receiver) not less than 0.3M and no more than 5M (working
angle +/- 15 degrees).
