Faulty or worn-out parts must always be replaced and not repaired. Only use
original spare parts: The use or non-original and/or incorrectly fitted parts will
compromise the safety of the machine, may cause accidents or personal injuries
for which the Manufacturer is under no circumstance liable or responsible.
unauthorized places!
described in this manual must be carried out by your Dealer or a specialized
Service Centre. Both have the necessary knowledge and equipment to ensure
that the work is done correctly without affecting the safety of the machine.
You must go to a specialized Service Centre or contact your Dealer of the following
are malfunctioning:
– the brake;
– the engagement and stop of the blade;
– the drive engagement in forward and in reverse gears.

6.2 ROUTINE MAINTENANCE

6.2.1 Engine
Follow all the instructions in the engine manual.
To drain the engine oil:
6.2.2 Transmission and gear unit
These are sealed single units which do not require maintenance. They are permanently
- 64 -
Never use the machine with worn or damaged parts.
Never get rid of used oil, fuel or other pollutants in
Any adjustments or maintenance operations not
1. unscrew the topping up cap (1);
2. fit the pipe (2) onto the syringe (3) (on request)) and
insert it
right into the hole;
3. using the syringe (3) (on request), suck up all the
engine oil,
bearing in mind that you need to repeat this
operation a few times before all the oil is removed.
