Troubleshooting

Symptom working
state
No signal
Level is too low
(analogue input)
Level is too low
(digital input)
Sound is too quiet or
distorted
Even at low output
level of the source,
the sound pressure
level in the room is
too high
The right channel can
be heard on the left
side and vice versa
(digital input)
Loud hum
Soft hum (during
pauses)
Soft noise
Possible problems
No mains connection or fuse blown
Power switch in OFF position
No input signal
Source (mobile phone, mp3-player,
CD-player) has too low output level
There is an attenuator at the source
side working
Gain of the powered speaker is set
to a low level
Gain of the powered speaker is set
to a high level
Channel switch is switched to the
wrong positions.
Contact problems with connectors
(especially RCA or adapters for ex-
tensions)
Hum of source, ground loop with
RCA multi-connections
Source reproduces noise
Solution
Check fuse, mains plugs and socket.
Switch to "ON".
Check input connections, exchange RCA con-
nector, check source signal (is a different audio
component fed by the same source playing cor-
rectly?).
Check and increase level adjustment at the
source device.
Increase the volume of the digital output at your
source.
Reduce the level of the source to appr. 50%,
switch the gain control switch of the powered
speaker to a more sensitive position until a
comfortable volume is reproduced within the
room.
Reduce the gain of the powered speaker to min-
imum; increase the output level of the signal
source to appr. 50%; now increase the gain of
the powered speaker until a comfortable volume
is reproduced within the room.
Select other channel on both speaker's channel
switches.
Check all connections; reduce the level at ELAC
speaker to min., the outer rings of the RCA
plugs may have to be readjusted.
Check of ELAC speaker for inherent hum: dis-
connect all inputs, switch power ON, normal set-
tings.
Now, with the ear near the speaker there may
be a soft hum, but none at the listening place.
Check of ELAC speaker for inherent noise: dis-
connect all inputs, switch power ON, normal set-
tings.
Now, with the ear near the speaker there may be
a soft noise, but nearly none at the listening
place.
