GB

5. Technical data

Asynchronous motor
Input power
Operating mode
Idle speed n
0
Carbide saw blade
Number of teeth
Weight
Tilting range
Mitre cuts
Sawing width at 90°
Sawing width at 45°
Sawing width at 2 x 45°
(double mitre cuts)

Noise emission values

The sawʼs noise is measured in accordance with
DIN EN ISO 3744; 11/95, E Din EN 31201; 6/93,
ISO 7960 Annex A; 2/95. The machine may
exceed 85 dB(A) at the workplace. In this case,
noise protection measures need to be introduced
for the user (ear-muffs).
operating
Sound pressure level L 104,4 dB(A) 94,2 dB(A)
pA
Sound power level L 111,4 dB(A) 107,2 dB(A)
WA
„The quoted values are emission values and not
necessarily reliable workplace values. Although there
is a correlation between emission and immission
levels it is impossible to draw any certain conclusions
as to the need for additional precautions. Factors
with a potential influence on the actual immision level
at the workplace include the duration of impact, the
type of room, and other sources of noise etc., e.g.
the number of machines and other neighbouring
operations. Reliable workplace values may also vary
from country to country. With this information the
user should at least be able to make a better
assessment of the dangers and risks involved."
12
19.09.2008 13:31 Uhr
6. Before putting the machine into
operation
230 V ~ 50 Hz
The machine has to be set up in a stable
1200 W
position, i.e. it has to be bolted to a workbench, a
S1
universal stand or the like.
All the covers and safety devices have to be
5000 rpm
properly fitted before the machine is switched on.
ø210 x ø30 x 2,5 mm
It must be possible for the saw blade to run
24
freely.
When working with wood that has been
8,8 kg
processed before, watch out for foreign bodies
-45° / 0° / +45°
such as nails or screws etc.
0° to 45° to the left
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
max. 120 x 60 mm
machineʼs moving parts run smoothly.
max. 80 x 65 mm
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
80 x 35 mm
6.1 Setting up the saw (Fig. 12)
Screw the additional stability bar (32) to the back
of the machine.
6.2 Adjusting the saw (Fig. 1/2)
To adjust the turntable (8), loosen the locking
grip (10) by approx. 2 turns, which frees the
turntable (8).
The turntable (8) has locking points at angles of
0°, 15°, 22,5°, 30° and 45°. Once the turntable
(8) is engaged, the setting must be additionally
secured by tightening the locking grip (10).
Idling
If you need to work with any other angles, the
rotary table is fixed in position with just the
locking handle (10).
Lightly press the machine head (4) down while at
the same time pulling the retaining pin (16) out
from the motor mounting; this causes the saw to
move down to the lower working position.
Swing up the machine head (4).
By loosening the lock screw (12), the machine
head (4) can be angled to the left up to 45°.
Check that the voltage marked on the rating
plate is the same as your mains voltage and
connect up the machine.
6.3 Precision adjustment of the stop rail (Fig. 5/6)
Lower the machine head (4) and fasten in place
with the safety pin (16).
Fasten the turntable (8) in 0° position.
Place the 90° stop angle (a) between the blade
(5) and the stop rail (7).
Slacken the adjustment screws (28), set the stop
rail (7) to 90° in relation to the saw blade (5) and
retighten the adjustment screws (28).
