Maximum inward
current 20 A
(for maximum 15
seconds)
Overload protection
200 mA / 250 V „F"
type fuse
20 A measuring range not protected!
Frequency range 40-
400 Hz
Capacity
Range Accuracy
20 nF
200 nF
+/- (2,5% +
2 μF
20 μF
200 μF +/- (5% + 4)
Transistor hFE-Test
Function Description
The amplification
factor of the transis-
h tor is measured
FE
(0-1000)
(All types)
Resistance
Range Accuracy
200 Ω +/- (0,8% + 5)
2 kΩ
20 kΩ
+/- (0,8% + 3)
200 kΩ
2 MΩ
+/- (1,0% +
20 MΩ
+/- (5,0%+
200 MΩ
Overload protection
20 A (höchstens 15
Sekunde lang)
200 mA / 250 V
Sicherung mit„F"
Zeichen
40-400 Hz
Resolution
10 pF
100 pF
20)
1 nF
10 nF
100 nF
Test state
Base current
appr. 10 μA
VCE appr.
2,8 V
Resolution
0,1 Ω
1 Ω
10 Ω
100 Ω
1 kΩ
10 kΩ
15)
100 kΩ
20)
250V DC/AC RMS
Temperature (with a K type temperature
sensor
Range Accuracy
-40 °C–400 °C +/- (0,8%+4)
400 °C–1000 °C +/-(1,5%+15)
Diode-Test
Function Description
The opening vol-
tage is measured
A beeping
sound indicates
if the resistance
between the V/
Ohm and COM
connectors is less
than 90 Ω
Overload protection
Frequency
Range Accuracy
2 kHz
20 kHz
200 kHz +/-(0,5%+4)
2 MHz
10 MHz
Overload 250 V DC / AC RMS (for
protection maximum 15 seconds)
Inductance
Range Accuracy
2 mH
20 mH
+/-(2,5%+5)
200 mH
2 H
20 H +/-(0,5%+4)
Warning: Do not connect external voltage
source to the connectors!
