Die Rückseite; Netzanschluss - T.C. Electronic D-TWO Bedienungsanleitung

BALANCED INPUTS BALANCED OUTPUTS
LEFT RIGHT LEFT
Symm.
Symm.
Analoge
Analoge
Eingänge
Ausgänge
(Linker
Eingang für
Mono-Betrieb)
MIDI-Kabel
DIN-Buchse
5polig – männlich
45 Grad
Stecker (asymm.) – XLR
Manschette – Pin 1 (Masse)
Spitze – Pin 2 (Signal)
Ring – Pin 3 (leer)
8
DIE RÜCKSEITE
DIGITAL I/O
RIGHT IN
DI
S/PDIF
DO
Digitaler
S/PDIF
Ein- &
Ausgang
Abgeschirmtes Kabel (3 oder 5 Adern + Abschirmung)
Spitze
Masse
MIDI PEDAL
IN
THRU OUT
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE
AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS
OUVRIR.
PROFESSIONAL AUDIO EQUIPMENT
THIS CLASS B DIGITAL DEVICE MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-
CAUSING EQUIPMENT REGULATIONS AND COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION SUBJECT TO CONDITIONS STATED IN THE MANUAL.
MIDI
Pedal-
IN, OUT,
eingang
THRU
max. 10m
Jack (balanced) - XLR
Manschette – Pin 1 (Masse)
Spitze – Pin 2 (Signal)
Ring – Pin 3 (leer)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SERIAL NO.
TYPE: MAN001
WARNING MADE IN THAILAND
TC ELECTRONIC
C
100-240VAC
50-60Hz, 15W

Netzanschluss

DIN-Buchse
5polig – männlich
45 Grad
Spitze
Ring
Masse
UL6500
R EN/IEC 60065
US
