GRAUPNER JOHANN FIDI Montageanleitung Seite 24

17 Rudder shaft
18 Rudder blade
19 Tiller
20 Rudder servo
21 Heat-shrink sleeve
22 Rudder pushrod
23 Pushrod retainer clip
24 Guard bar
25 Retaining pin
26 Daughter boat lift retaining rod
27 Gusset
28 Hook retaining bar
29 Retaining bar reinforcement
30 Stern fender rail
31 Salvage port fender rail
32 Exhaust ring
33 Deck
34 Lashing hook recess
35 Lashing hook
36 Forecastle deck fairings
37 Lateral fender rail
38 Deck edge strip
39 Bollard
40 Rudder cover ring
41 Flagstock
42 Flagstock truck
43 Grappling hook holder
44 Cockpit back panel
45 Hatch
46 Hinge
47 Handrail
48 Engine cowl hinge
49 Command stand base plate
50 Corrugated sheet
51 Base plate support
52 Cockpit floor
53 Life-jacket cable holder
54 Life-jacket
55 Life-jacket back section
56 Towing hook running rail
57 Running rail stop
58 Towing hook holder
59 Towing hook
60 Superstructure
61 Inner superstructure frame
62 Superstructure back panel
63 Roof panel
64 Side window frame
65 Front window frame
66 Roof hatch hinge
67 Roof hatch latch
68 Instrument panel
69 Port reinforcement
70 Starboard reinforcement
71 Door
72 Hinge
73 Porthole frame
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
Keine Haftung für Druckfehler. Technische Änderungen vorbehalten! Liability for printing errors excluded. We reserve the right to introduce modifications. Sous réserve de modifications!
Nous ne sommes pas responsables d'éventuelles erreurs d'impression!
1 Brass
2 ABS
1 Plastic
1 Plastic
1 Plastic
1 Steel
2 Plastic
5 ABS
1 Steel
1 Plastic
2 ABS
1 ABS
1 Plastic
2 ABS
1 ABS
1 ABS
1 ABS
6 ABS
6 ABS
2 ABS
2 ABS
3 ABS
8 Plastic
1 ABS
1 Steel
1 ABS
2 ABS
1 ABS
1 ABS
2 ABS
1 ABS
2 ABS
1 ABS
1 ABS
2 ABS
1 ABS
2 Plastic
2 ABS
2 ABS
1 ABS
4 ABS
2 ABS
6 Plastic
1 ABS
1 ABS
1 ABS
1 ABS
6 ABS
3 ABS
1 ABS
2 ABS
1 ABS
1 ABS
1 ABS
1 ABS
3 ABS
1 ABS
#0058777
Rod, 3 mm Ø x 60 mm
1 mm, laser-cut
Ready made, requires assembly
Order No. 5114
Cut to servo length + 4 mm
Cut to approx. 45 mm long, bend as plan
Ready made
1 mm, laser-cut
Rod, 1.5 Ø x 10 mm
"Snake" outer, 3 2 / 2.2 Ø x 24 mm
1 mm, laser-cut
1 mm, laser-cut
"Snake" outer, 3.2 / 2.2 Ø x 17 mm, trim
to follow hull shape
Half-round strip, 3 / 1.4 x 30 mm
Half-round strip, 3 / 1.4 x 58 mm
1 mm, laser-cut
1 mm, vac.-moulded, CNC
1 mm, vac.-moulded
1 mm, laser-cut
1 mm, laser-cut
Half-round strip, 3 / 1.4 x 216 mm
Round strip, 1.5 Ø x 260 mm, requires
trimming to fit
Ready made, 6 off, requires trimming
1 mm, laser-cut
Rod, 1.5 Ø x 40 mm
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
Round strip, 2 Ø x 150 mm
1 mm, laser-cut
1 mm, laser-cut
0.5 mm, vac.-moulded
1 mm, laser-cut
1 mm, laser-cut
"Snake" outer 3.2 / 2.2 Ø x 15 mm
1 mm, vac.-moulded
From 1 mm ABS scrap
Square strip, 3 / 3 x 108 mm
1 mm, laser-cut
1 mm, laser-cut
Ready made, requires assembly
1 mm, vac.-moulded, CNC
1 mm, laser-cut
1 mm, vac.-moulded
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
1 mm, laser-cut
24
11/2007
