TOOLPORT PVC Gebrauchsanweisung Seite 8

Contents
Part no. Description
30490 pipe 1170 mm 50-50
30513 pipe 1925 mm 38-38
30413 pipe 1925 mm
38-38 with hole
30517 pipe 1225 mm
roof brace
5-series horizontal
30518 pipe 440 mm
roof brace
5-series vertical
30437 pipe 1174 mm
25-25 diagonal pipe
30414 pipe 2488 mm
50-50 with holes
30415 pipe 2488 mm
50-50 with holes
and a hole
30432 pipe 1582 mm
38-38
30416 connector three way 110°
54-42
30417 connector three way 140°
54-42
30418 connector four way 140°
54-42
30419 connector four way 110°
54-42
30420 cross piece
54-42
30421 T-piece
30422 connector three way – foot
for the corners 54-42
30423 connector three way – foot
for the side walls
54-42
ID no.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
®
5x6m 5x8m 5x10m 5x12m
16 20 24 28
17 24 31 38
4 4 4 4
8 10 12 14
4 5 6 7
4 4 4 4
4 6 8 10
4 4 4 4
6 6 6 6
4 4 4 4
2 2 2 2
2 3 4 5
4 6 8 10
4 6 8 10
4 4 4 4
4 4 4 4
4 6 8 10
