Pull-up station
FR IT DE PT NL SW PL DA
EN
ES
MULTIFIT
Step 5.
Connect the back cushion (J) and the rear tube (F) with the screws (d) (M8*14).
Step 6.
Place the straight side of the adjustable tubes (G) on the main tube (B), use the adjustable screws (a) to
choose the right height. Finally, connect the handlebar (H) and the adjustable tubes (G) with the 2 sets of
screws of the combination (i) - Screw (M8*65) + Washer (M8) + Nut (M8).
15
