APRAMO modul one Bedienungsanleitung Seite 8

06
IMPORTANT:
DO NOT OPEN THE BUCKLE BEFORE LOOSENING THE HARNESS.
THIS COULD PREVENT THE CHILD FROM BREATHING NORMALLY.
®
2.4 Removal of the apramo modül | one i-Size new born & baby
car seat
Open the vehicle safety belt buckle (Fig. 6) and remove the diagonal
belt from the upper belt guide (4) and then remove the lower portion
of the safety belt from the front belt guides (3).
3
installation with apramo ® modül | hub-
®
3.1 Installation of the apramo modül |
1. For easy installation of the base, we recommend inserting the
plastic guides on the ISOFIX anchor points of the vehicle (Fig. 11).
2. Rotate the support leg (18) of the base to the maximum angle (Fig.
12).
3. Once you've pressed the ISOFIX extension button (14), the ISOFIX
seat (Fig. 12).
4. Insert the ISOFIX connectors of the base to the vehicle ISOFIX
anchors and then push lightly until you hear two "clicks". The
ISOFIX connection indicators (22) should turn from red to green
(Fig. 13).
GB
installation with apramo ISOFIX rotating base
®
5.
button (14) again while pushing the base towards the vehicle seat
backrest until the anti-rebound system (20) is in contact with
the backrest. Once this is achieved, stop pressing the ISOFIX
extension button (Fig. 14).
6. Press the support leg adjustment button (19) and then put the
indicators on the support leg turn from red to green (Fig. 15).
7. Then the base is correctly installed.
®
3.2 Installation of the apramo modül | one i-Size new born & baby
car seat on apramo ®
The apramo ® modül | one i-Size new born & baby car seat can be
used from 40 to 75 cm / ≤ 11 kg for your baby.
®
1. Make sure that the apramo modül | ISOFIX rotating base
2.
To install the infant carrier on the apramo ® modül | ISOFIX
rotating base, you must press the rotation lever (17) and turn the
rotation plate (15) of the base to the position as shown in Fig. 18.
The seat release strap (16) must face you. This will allow you to
place the child in the infant carrier more comfortably.
IMPORTANT:
NEVER TRY TO INSTALL THE INFANT CARRIER ON THE BASE
IN THE OPPOSITE DIRECTION. ALWAYS MAKE SURE THE SEAT
RELEASE STRAP (16) IS AT THE SAME SIDE AS THE CHILD-FACING
DIRECTION. THE INSTALLATION OF THE INFANT CARRIER ON
THE BASE IS POSSIBLE ONLY WHEN THE ROTATION PLATE IS
POSITIONED AS SHOWN IN FIG. 23
installation with apramo ISOFIX rotating base
®
3. Place the infant carrier on the apramo ® modül | ISOFIX
rotating base by matching the rods with the base locking guides
two "clicks" are clearly heard (Fig. 18). Shake the carrier slightly to
4. Press the rotation lever (17) (Fig. 19) and secure the infant carrier in
the rearward-facing direction (Fig. 21).
5.
that the carrier is locked in its correct position.
Press the carrying handle release button (5) and rotate the
6.
carrying handle (1) against vehicle seat backrest (Fig. 22).
IMPORTANT:
BEFORE SETTING OFF, MAKE SURE THE INFANT CARRIER IS IN
REARWARD FACING DIRECTION (Fig. 24). TO AVOID RISK OF
MISUSE, THE BASE IS EQUIPPED BY A MECHANICAL STOPPER
THAT PREVENTS THE INFANT CARRIER TO BE ROTATED FORWARD
FACING, ONCE IT'S CORRECTLY HOOKED TO THE BASE. DO NOT
FORCE THE ROTATION OVER THE LIMITS OF THE STOPPER.
7. The modül | one Infant Carrier is now installed correctly.
WARNING!
NEVER ATTEMPT TO PLACE THE INFANT CARRIER IN FORWARD-
FACING DIRECTION. IT CAN BE EXTREMELY DANGEROUS FOR
YOUR CHILD IN THE EVENT OF AN ACCIDENT.
3.3 Securing your child
® modül | isize family has a loading position (turn 90°
The apramo
to vehicle door) to facilitate the installation of your child. To do this,
please follow the below steps methodically:
1. When the apramo ® modül | one i-Size new born & baby car seat
® modül |
is installed on the apramo ISOFIX rotating base,
rotate the infant carrier to the loading position (Fig. 19).
2.
Release the harness by pressing the quick adjuster (11) and pulling
the harness strap (9) just above the buckle (Fig. 3). Press the red
button to open the harness buckle (10) (Fig. 6).
3. Place your child in the infant carrier. Pass the harness around
the child's shoulder, close the buckle by joining the two tongues
and joining them together into the buckle body (Refer to Fig. 6 in
reverse order). Remember not to place your child in thick clothes
as this will reduce the child's level of safety in the event of an
accident.
4. Adjust the headrest of the infant carrier by pulling the headrest
adjustment lever (6) that is located on the top (Fig. 1). The correct
position of the head restraint is horizontal to or a little bit below
the top of your child's shoulder (Fig. 2).
5. Adapt the harness by pulling on the adjustment strap (12) (Fig. 4).
As a reference, the correct harness tension is considered if there
is a maximum of 1 cm between your child's body and the harness.
6. Your child is now correctly secured.
7.
Ensure that your child's both arms and legs remain inside the child
seat structure. By pressing the rotation lever (17), turn the seat to
rearward-facing position and make sure that the carrying handle (1)
is rotated against the vehicle seat backrest (Fig. 22).
3.4 Safe removal of your child
1. Rotate the infant carrier to the loading position (Fig. 19).
07
GB
