Description
The RB2016 is a card with 18 relay outputs to interface the
FP2000 Series Fire Panels to external devices. The card is
delivered with the necessary washers, nuts and spacers to
allow for proper mounting.
Figures
Figure 1:
(1) Nut
(2) Washer
(3) Nylon spacer
Figure 2: Jumpers T1 to T8
(1) Position A = Termination for external supervision
(2) Position B = No termination for external supervision
(3) Output
Figure 3: Outputs 9 to 18
(1) (T9 to T18) Position A = Termination for external supervision
(2) (T9 to T18) Position B = No termination for external supervision
(3) (J9 to J18) Position A = NO Selection
(4) (J9 to J18) Position B = NC Selection
(5) Output
Figure 4: Top layout of RB2016
Installation
The RB2016 card plugs directly into the bus (FEP, Loop
Driver) positioned in the rear of the cabinet and is mounted in
position using the hardware supplied with the card.
To install the card:
1. Disconnect all power (mains and batteries).
2. Set jumpers - if necessary. [1]
3. Mount the RB2016. Pay attention to the arrangement of
the nuts, bolts and spacers.
4. Connect the outputs as required. [1]
5. Connect power.
6. Reconfigure the fire panel. [2]
Outputs are numbered 1 to 18. One jumper is provided for
outputs 1 to 8 and two sets of jumpers for outputs 9 to 18.
Refer to Figure 2 for outputs 1 to 8 and Figure 3 for outputs 9
to 18.
[1] See the FP2000 Series Installation & Commissioning Manual.
[2] See the FP2000 Series Reference Guide.
Fail-Safe Fault Output
When the fault jumper (J222) has been removed, the fault
output is fail-safe. This means that when the fault line has been
activated the fault relay (output 17) will fall out (change state).
When the fault jumper (J222) has been inserted the fault
output is not fail-safe. This means that when the fault line has
been activated the fault relay (output 17) will not fall out
(change state). In this state, the fault output can be used as a
normal relay output.
2 / 4
Board Layout
Figure 4 is the top layout of the RB2016. To avoid confusion,
ensure that the PC-board number with revision level
(0738-2B), on the left-hand side, coincides with the number in
Figure 4 on this leaflet.
Refer to Figure 4 for the specific positions of the jumpers and
the relays.
Regulatory information
Conformity
Carrier Manufacturing Poland Spółka Z o.o.,
Manufacturer
Ul. Kolejowa 24, 39-100 Ropczyce, Poland.
Authorized EU manufacturing representative:
Carrier Fire & Security B.V., Kelvinstraat 7,
6003 DH Weert, Netherlands.
2012/19/EU (WEEE Directive): Products
marked with this symbol cannot be disposed of
as unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collection points. For more
information see: recyclethis.info.
Contact information and product
documentation
For contact information or to download the latest product
documentation, visit firesecurityproducts.com.
Product warnings and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO AND
INSTALLATION BY QUALIFIED PROFESSIONALS.
CARRIER FIRE & SECURITY B.V. CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED DEALER" OR
"AUTHORIZED RESELLER", IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE AND
SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers
and product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code:
DE: Installationsanleitung
Produkt Beschreibung
Die RB2016 ist eine Relaiskarte mit 18 frei programmierbaren
Relais-Ausgängen für die Montage in der Zentralenserie FP
2000. Das Board wird mit Schrauben, Unterlegscheiben und
Distanzstücken für die Befestigung in der Zentrale geliefert.
P/N 10-3319-501-RB20-03 • ISS 20JUN22
