Installation
How to establish a connection within the terminal emulator:
NOTE: Before establishing a connection using the terminal emulator, install the
device driver CP210x USB to UART Bridge VCP.
This driver provides the Service port of the
connected via service cable, as virtual serial interface (COM port). Now, the
virtual interface can be selected in the terminal emulator to establish the
connection.
The driver is provided as download on the website
Service > Tools & drivers.
1. Start any terminal emulator (e.g. HyperTerminal or PuTTY).
2. Establish a new connection in the terminal emulator and enter the following settings:
 Bits per second: 115.200
 Data bits:
 Parity:
 Stop bits:
 Flow control:
3. Use a data cable to connect the computer to the Service port at the front panel of the
DynamicWorkplace-CON
NOTE: To log in into the service menu, enter the user name service and the
password service.
4. In the service menu, you have the following options:
 Quit
 System information
 Set system defaults: A confirmation Are you sure? [y]es, [N]o (default) is displayed.
 Reboot: A confirmation Are you sure? [y]es, [N]o (default) is displayed.
16 · G&D DynamicWorkplace-CON
8
none
1
none
.
DynamicWorkplace-CON
www.gdsys.com/en
system, which is
under
