Installation of REMOCON NET MINI
Types of possible installations
Type 3
Activation of RC in a basic hybrid system
(Fig. 3)
System in which the ELCO product is
connected exclusively to a single
temperature regulation accessory and in
which the REMOCON NET Remote
Control and Remote Assistance services
must be activated. It is possible to
remotely control the cooling function, if
available.
Actions required:
· Install REMOCON NET MINI and
REMOCON PLUS, connecting them to
the heating product using the BUS
BridgeNet connection
Type 4
Activation of RC in a basic hybrid system
with hot water cylinder (Fig. 4)
System in which the ELCO product is
connected exclusively to a single
temperature regulation accessory and in
which the REMOCON NET Remote Control
and Remote Assistance services must be
activated. It is possible to remotely control
the cooling function, if available.
Actions required:
· Install REMOCON NET MINI and
REMOCON PLUS, connecting them to
the heating product using the BUS
BridgeNet connection
NOTE:
For information on other possible
schemes, contact the ELCO technical
assistance center.
Fig. 3
Fig. 4
Replacement of an accessory or a
board that offers connectivity features
If you are replacing a connectivity
accessory or an electronic bard that offers
connectivity features, it is recommended
to reset the function by following the
instructions in the original manual before
proceeding to reconnect to the internet.
Alternatively it will still be possible to carry
out the replacement and proceed to
reconnect the product by following the
instructions within the App.
46
REMOCON REMOCON
NET MINI PLUS
REMOCON REMOCON
NET MINI PLUS
