Product description
4 Product description
4.1 Product identification
4.1.1 Variants
(1) (2) (3)
HiPace 2300
4.1.2 Pump features
4.1.3 Scope of delivery
50
The product designation consists of a family designation (1), the size (2), which is orient-
ed on the pumping speed, and if applicable the additional properties (3) of the pump.
1. Family designation
HiPace
This product has been tested to the requirements of CAN/CSA-C22.2 No. 61010-1, sec-
ond edition, including Amendment 1, or a later version of the same standard incorporat-
ing the same level of testing requirements.
For information about other certifications, if applicable, please see the signet on the prod-
uct or:
● www.tuvdotcom.com
● TUVdotCOM-ID 0000021320
Characteristics
HV flange
Flange material
To correctly identify the product when communicating with Pfeiffer Vacuum, always have
the information from the rating plate available.
D-35614 Asslar
---
HiPace 300
Oil:
Mod.:
S(N ): 260 l/s
DN 100 ISO-K, 3P
2
60000 1/min, 1000 Hz
n,f:
PM P03 900
M.-No.:
Ser. -No.: 6.7 kg
Weight:
Made in Germany
Fig. 20: Example for a rating plate
● Turbopump for external electronic drive unit
● Protective cover for the high vacuum flange and the fore-vacuum flange
● Sealing gas valve
● Operating fluid (50 ml) with filling syringe
● Screw-in nozzle (2x) with seal ring for cooling water connection
● Eye bolts
● Operating instructions
2. Model designation
2300 = Model designation of
the pump related to its pump-
ing speed class
DN 250 ISO-K
Aluminium
3. Property designation
none = Standard version
U = Upside-down installation orientation
C = Corrosive gas version
P = Process
M = Active magnetic bearing
T = Temperature management system
E = High Efficiency
H = High Compression
I = Ion implantation
HiPace 2300
DN 250 ISO-F DN 250 CF-F
Aluminium Stainless steel
