(Figure 1B). Push the button inward according to the Figure 1C, and adjust the handle into
its normal position.
INSTALLATION OF FRONT AND REAR WHEELS
Installing and removing the front wheels: As shown in Figure 2A, insert the front wheel
into the front frame hole. Fix it until you hear a "click". To remove the front wheels, press
the button and the wheels are removed easily by pulling (Figure 2B).
Orientation of the front wheels: Press the front wheel orientation button as shown in the
direction of the arrow, the front wheels cannot rotate (Figure 2C). Raise the button as
shown in the direction of the arrow, the front wheels can be rotated 360 degrees.
Installing and removing the rear wheels: As shown in Figure 3A, insert the rear wheel into
the hole of the rear frame. Fix until you hear a click. To remove the rear wheels, push the
button and the wheels are released quickly by pulling (Figure 3B).
USING THE BRAKE: To activate the parking device and lock the two rear wheels, press down
the pedal on the rear axle (Figure 4A). To release the brake, pull up the pedal using your
foot (Figure 4B).
SEAT ASSEMBLY: To install the seat, put it in the frame holes until you hear a click sound
(Figure 5A). To remove the seat, press the buttons on both sides at the same time. Then,
pull the seat up to remove it (Figure 5B).
ATTACH AND DETACH THE SAFETY BOARD: Insert both ends of the safety board into the
two side holes of the frame. Secure the guard until you hear a click (Figure 5F). To remove
the guard, press the release button on both sides of the frame and pull at the same time
(Figure 6G).
ADJUSTING THE FOOTREST: As shown in Figure 9, move the step up and the angle can be
adjusted. To adjust the footrest, hold the button on both sides for its release.
ASSEMBLING THE CANOPY: Insert both sides of the canopy into the rear holes of the seat
until you hear a click. Press fully (Figure 6A). Pull the zipper behind the seat (Figure 6B).
FOLDING AND UNFOLDING THE STROLLER: First press the second lock button and pull the
release button up, then press the entire button down (Figures 6C1 and 6C2). Fold the
stroller completely until you hear a click sound and the folding hook is secured (as in Figure
D). Adjust the handle to the folding position (reduces the size of the fold) (Figure 7).
Attention! When closing the trolley, make sure your child or other children are kept at a
safe distance. Make sure the moving parts of the trolley do not come in contact with your
child during these operations. Before closing the cart, make sure the storage bin is empty.
INSTRUCTIONS FOR MAINTENANCE AND CLEANING
1. Regularly check the locking devices, brakes, safety belts and buckles, connectors, and fixing
mechanisms in order to be sure that they are in good working order and are not worn or
damaged.
2. If you find loose, broken, and damaged parts, they should be repaired by an authorized service
or replaced with original parts. Otherwise, the warranty of the stroller will be annulled.
3. Do not make modifications on the construction and do not replace the work parts with ones
that are поt suitable and are not original. This may lead to incorrect functioning of the stroller
and to injury of your child.
