1. Lid and pellet shovel
2. Glass tube
3. Knobs
4. Fixing ring
5. Product body
6. Upper ash collector inlet
7. Lower ash collector inlet
8. Cleaning brush
9. Ash scraper
10. Ash catcher
• Make sure that the installation instructions have been followed correctly.
• Place the heater in a suitable position, on a flat surface and away from areas susceptible to fire. The base of the product
will become hot, so it must be placed on a suitable surface. Always remember to respect the minimum safety distance of
at least 2 metres to the sides and height of the product.
• Carefully select the location where the heater is to be placed. Always place it on a firm and level surface. Small amounts
of burnt pellets and ashes may fall from the cooker, so always place it where there is no danger of it catching fire. If in
doubt, place it on a patio slab or similar.
1. Slide the glass tube through the fixing ring. When the tube is lowered close to the position of the shelf support, hold the
glass tube and the fixing ring, tilt them forward and rest the lower end of the glass tube on the shelf support.
8 E N GL ISH
LIST OF PARTS
1
2
3
4
5
HOW TO USE
8
6
7
Shelf support
9
10
