SOMFY Amy 1 Modes io Anleitung Seite 14

EN
1] Insert a flat screwdriver inside the hole at the bottom of the circular back
cover to easily eject the module from its support or, if the mounting plate and
its square frame are being used, manually remove the module from its
supports by pulling it towards you.
2] On the back of the module, remove first side of the battery cover by pushing
on the clip. Then pulling on the middle part of the battery cover to release the
first side of the cover. Push on the second clip to completely release the
cover.
3] Remove the battery cover.
4] Insert a CR2032 battery (3 V) with the (+) polarity side visible (on top), Slide it
and push to engage on the right side of the battery contact. Then insert the
stops of the cover on the bottom.
CAUTION
• Ensure you comply with the polarity.
• The power supply terminals must not be short-circuited.
5] Press on the top of the cover to engage the clips.
6] Clip the module onto the circular back cover or onto the square frame and
clip the square frame assembly onto the mounting plate again.
3.7.Tips and advice on use
3.7.1.Questions about the product?
Observations
The selected motorised product does not react
at all when a button on Amy 1 Modes io is
pressed (No LED reaction when pressing the
buttons).
The selected motorised product does not react
at all when a button on Amy 1 Modes io is
pressed (No LED reaction in the front when
pressing a button AND in the back when pressing
the On/Off button).
The selected motorised product does not react
at all when a button on Amy 1 Modes io is
pressed but the LED lights up.
The selected motorised product does not react
at all when a button on Amy 1 Modes io is
pressed but the LED lights up and the control
point is paired with this motorised product.
The selected motorised product does not react
as it should.
The motorised product does not react when the
indoor temperature rises (the scenes
programmed in TaHoma in the event of a
change in indoor temperature do not launch).
NOTICE
If the product still does not operate, contact a drive and home automation professional.
14
Possible causes
Amy 1 Modes io is switched off, the
front panel buttons (Up, Stop/my,
Down) are deactivated.
The control point battery is low.
The control point is not paired with
this motorised product.
External radio equipment is
interfering with the radio reception.
The selected mode does not match
the type of motorised product.
The temperature feedback to
TaHoma is deactivated on Amy 1
Modes io.
Copyright
1]
2]
3]
4]
5]
Solutions
Switch it on to activate the buttons
(refer to Switching on Amy 1
Modes io).
Change control point battery as
required (refer to Replacing the
battery).
Refer to Adding/Deleting Amy 1
Modes io.
Turn off any nearby radio
equipment.
Refer to Mode selection.
Check sensor status on TaHoma
application and refer to Use with
TaHoma if necessary.
©
2024 SOMFY ACTIVITES SA. All rights reserved.
Amy 1 Modes io
