3. Symbols
Read the operating instructions carefully!
The article is not suitable for children under 3 years!
MODEL AND PARAMETERS
Model
Weight Capacity
Ages
Number
Assembled Dimensions
ASSEMBLY AND USE
Part List:
Part Mx4 (Long
Blue Tube)
Part Ex12 (Long
Bolt)
Part Ix2
Note: Be careful not to confuse Part N with Part M, and let Part N aside for using at
the last step.
Part Nx1(Long &
Thicker Blue
Tube)
Part Fx8 (Short
Bolt)
Part Jx1
600 lbs （272kg)
6FT.W × 3FT.H
Part Ax20 (Short Part Bx24 (Yellow
Blue Tube)
Part Gx8 (Lock
Nut)
Part Kx12
7
JX-DC-06
3-9
2-3kids
Part Dx12 (Long
Tube)
Part Hx28
(Washer)
Part Cx12
Nut)
Part Lx2
