Aqmos R2D2-32 Betriebsanleitung Seite 51

Item No. Part. No.
A01 05056087 Screw-M5x12 (Hexagon)
A02 05056088 Screw-M5x16 (Hexagon with Washer)
A03 05056047 End Plug Retainer
A04 05010081 Bnt65 Piston Rod
A05 05056097 Piston Pin
A06 05056023 End Plug
A07 05056070 Quad ring
A08 05056024 End Plug Washer
A09 05056022 Piston Retainer
A10 05056181 Piston (Electrical)
A11 05056104 Muffler
A12 05056021 Spacer
A13 05056073 Seal
A14 05056019 Bnt65 Valve Body
A15 05056063 O-ring q78.74x5.33
A16 05056129 O-ring q23x3
A17 05056025 Adaptor Coupling
A18 05056044 Adaptor clip
A19 05056090 Screw ST4.2x13 (Hexagon with Washer)
A20 21709003 Secune Clip
A21 05056140 Valve Connector
A22 05056065 O-ring q23.6x2.65
A23 21319006 Screw adaptor
A24 26010103 O-ring q25x3.55
A25 07060007 Valve Bottom Connector
A26 13000426 Screw ST2.9x13 (Large Wafer)
A27 05010082 Drain Fitting-B
A28 05056134 O-ring 12x2
A29 05056172 Sesune Clip S
A30 05056186 DLFC-2#
A31 05056035 BL F C Button Retainer
A32 05056191 BL F C-2#
A33 05056138 O-ring 14x1.8
A34 05056100B BL F C Fitting
A35 05056106 Brine Line Screen
A36 05056107 BL F C Tube Insert
A37 05056033 BL F C Femule
A38 05056108 BL F C Fitting groove
A39 05056066 Screw-M6x30 (Hexagon with Washer)
A40 05056029 Injector cover
A41 05056072 O-ring q24x2
A42 05056103 Injector Screen
A43 05056027 Injector Nozzle
A44 05056028 Injector Throat
A45 05056177 Injector Body-B
A46 05056075 Injector Seat
A47 05056054 Injector spacer
Spare parts list valve neck BNT-165
Part Description Quantity
3
2
1
1
1
1
2
1
1
1
1
4
5
1
1
4
2
2
2
2
1
2
2
1
1
2
1
2
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
49
