Operating instructions
Universal thermostat
Item no. 2686283
1 Intended use
This product is a universal and easy-to-use electronic thermostat with a built-in digital display.
The product records temperature data over a wide temperature range via an external tem-
perature sensor and can be used either as a heating or cooling thermostat. It can be used in
automatic or manual mode.
The thermostat plugs into a mains socket and the connected device (load). It can switch loads
with a power input of up to 3680 W (230 V/16 A).
The temperature settings will be retained when the thermostat is disconnected from the mains
or if there is a power cut.
This product is intended for indoor use only. Do not use it outdoors. Contact with moisture (e.g.
in a bathroom) must be avoided under all circumstances. This product complies with statutory,
national and European regulations. For safety and approval purposes, you must not rebuild
and/or modify the product.
In addition, improper use can cause hazards such as a short circuit, fire or electric shock. Read
the operating instructions carefully and store them in a safe place. Only make this product
available to third parties together with its operating instructions. This product complies with
statutory, national and European regulations. All company and product names contained herein
are trademarks of their respective owners. All rights reserved.
2 Delivery content
Universal thermostat with sensor
3 Latest product information
Download the latest product information at
shown. Follow the instructions on the website.
4 Symbols in this document
This symbol warns of hazards that can lead to personal injury. Read the information
carefully.
This symbol warns of a dangerous voltage which can lead to injuries due to electric
shock. Read the information carefully.
5 Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling, we will assume no liability for any resulting personal injury
or damage to property. Such cases will invalidate the warranty/guarantee.
5.1 General information
This device is not a toy. Keep it out of the reach of children and pets.
Do not leave packaging material lying around carelessly. It may become a dangerous play-
thing for children.
Always observe the safety instructions for all devices connected to the product.
Should you have any questions or concerns after reading this document, please contact
our technical support or a professional technician.
5.2 Handling
Handle the product carefully. Impact, shocks or a fall even from a low height can damage
the product.
5.3 Operating environment
Do not expose the product to any mechanical stress.
Protect the product from extreme temperatures, strong jolts, flammable gases, vapours,
and solvents.
Protect the product from high humidity and moisture.
Protect the product from direct sunlight.
5.4 Operation
Consult an expert when in doubt about the operation, safety or connection of the device.
Only use the product in a dry and dust-free environment.
Operating instructions
www.conrad.com/downloads
or scan the QR code
If it is no longer possible to operate the product safely, stop using it and prevent unauthor-
ised use. DO NOT attempt to repair the product yourself. Safe operation can no longer be
guaranteed if the product:
– is visibly damaged,
– is no longer working properly,
– has been stored for extended periods in poor ambient conditions, or
– has been subjected to any serious transport-related stress.
5.5 Mains voltage
Never attempt to modify the electrical components of the product. Risk of fatal
electric shock!
Always ensure that the mains plug is properly connected.
Discontinue use of the device if any electrical components are damaged.
Do not modify the electrical components.
Only connect the product to a normal mains socket connected to the public supply network.
Before plugging in the product, check whether the voltage stated on the product complies
with the voltage of your electricity supplier.
Do not touch the product if there are any signs of damage, as this may cause a fatal electric
shock! Proceed as follows:
– First, cut off the power supply to the mains socket to which the product is connected
(switch off the corresponding circuit breaker or remove the safety fuse, and then switch
off the FI safety switch so that all poles of the mains socket are disconnected).
– Then unplug the product from the mains socket.
A damaged product may only be repaired by the manufacturer, a workshop commissioned
by the manufacturer, or a similarly qualified person so as to prevent any danger.
Unplug the product from the mains socket if you do not plan to use it for an extended
period of time.
Do not open the product. It does not contain any components that require maintenance
by the user. Opening the product may result in an electric shock. Return the product to
customer services for repair if it malfunctions.
Before connecting a load, ensure that you pay attention to the technical data, especially
the maximum permitted switching capacity of the relay and the type of the connected load.
All load data refers to resistive loads! Do not load the device over the specified power limit.
Overloading may destroy the product or cause a fire or electrical accident.
For safety reasons, disconnect the product from the mains socket during storms.
Never connect or disconnect the product when your hands are wet.
Adapters must not be plugged into each other.
Only use the product with permanently installed mains sockets with protective earth con-
tacts. Do not plug the thermostat into power strips or use extension cables.
Do not connect any devices to the thermostat that may cause a fire or other damage when
left unattended (e.g. irons).
Unplug the load from the thermostat before making changes (e.g. changing a light bulb).
Always lay cables such that they do not constitute a hazard to people and pets.
The product is not designed to be isolated. The load is not electrically isolated from the
mains.
The product is only isolated from the mains when it is unplugged from the mains socket.
Never cover the product during use.
Maintenance, modifications and repairs must be carried out by a technician or a specialist
repair centre.
