ledscom LC-L-380 Montagehinweise Seite 5

1. The scope of delivery includes two corks
(1) with different diameters. You can easily
replace the cork (1) by loosening the nut
(2), removing the washer (3) and pulling off
the cork (1). Then fit the appropriate cork
(1) and fix it in place using the washer (3)
and nut (2).
2. You can attach a shade to the socket
using the screw ring (4). To do this,
unscrew it (4), insert a suitable shade and
retighten the screw ring (4) hand-tight.
3. Now prepare the bottle for the cork.
Clean the bottle thoroughly inside and out.
If the bottle is not stable, we recommend
filling it with a non-conductive material (e.g.
sand) to weigh it down. Never fill the bottle
with a liquid.
4. Now place the cork in the bottle. The
installation is now complete.
Subject to technical changes
LEDs Com GmbH, Dohrweg 2a, D-41066 Mönchengladbach, www.leds-com.de, Tel. +49 (0) 2161 - 5 75 99 76
English
Figure 1
1: Cork
2: Mother
Table lamp (LC-L-380) - Assembly instructions
3: Washer
4: Screw ring
05/2024
