Installation
CAUTION
Damage to the device due to faulty electrical connection.
• I f the motor power circuit is interrupted by integrated limit switches, it must
not be connected with a semiconductor relay.
CAUTION
Damage or destruction of the device for versions with 230 V 1 AC caused by
faulty electrical connection.
• A parallel connection of several AC drives is impermissible. This requires
multipolar switches or cut-off relays.
• Both directions of travel must not be actuated simultaneously and this must
be prevented suitable precautions by the customer.
CAUTION
Damage or destruction of the device through ingress of moisture in the connec-
tion cables.
• F or devices with protection type IP 65 and IP 65s, the customer-provided
connection of the cable ends or connectors must also have IP 65 protection.
No circuit diagrams are listed below on account of the multitude of configuration
possibilities.
The device has to be connected in accordance with the circuit diagram enclosed
with the delivery.
Please refer to the following pages or the circuit diagram enclosed with the
delivery for connection of the option selected by you.
4.3 Optional attachments
4.3.1 Optional brake
CAUTION
Damage to the device due to incorrect connection of the brake.
• Operate the device only when the brake is released.
• Do not tap the brake voltage parallel to the motor.
With the integrated brake you can decelerate the stroke movement of the con-
necting rod faster and optimize the static safety.
To release the brake, connect the brake coil with conductor codes X1 and X2 to
the rated voltage of the brake in accordance with the type plate.
