INSTALLATION
• Be sure to remove all packaging material from inside the
appliance.
ASSEMBLING THE WALL BRACKET:
• The appliance has a wall bracket (M.4) which must be
fixed to the wall.
• Fix the wall bracket as you think appropriate, using plugs,
screws.
• Make sure that the bracket is firmly fixed; it should be
able to support twice the weight of the appliance.
• Fit the appliance into the wall support.
CHARGING THE BATTERY
Caution: A new battery is not fully charged and must
therefore be charged before the appliance is used for the
first time.
• Charge the battery at an atmospheric temperature of
between 4 and 40 ºC.
• Approximately 4 to 5 hours are needed for a complete
charge of the battery. Never attempt to over-charge the
battery (although it is recommended that the first charge
of the battery be of 6 hours in duration).
• You can charge the battery completely assembled or
disassembled from the main body.
• The charging indicator lights (E) will come on to indicate
that the charger is charging the battery.
• If the battery is assembled into the main body, the led
screen (2) will show the battery % level.
• When the battery is charged, disconnect the charger from
the mains supply.
Note: Do not use the appliance while it is connected to the
charger.
INSTRUCTIONS FOR USE
BEFORE USE
• Make sure that product's packaging has been removed.
• Please read carefully the "Safety advice and warnings"
booklet before first use.
• Before using this product for the first time, it is important
to make a full charge of batteries.
• Prepare the appliance according to the function you wish
to use.
VACUUMING FUNCTION
• Fit the tube unit to the main body
• Fit the desired accessory to the tube.
• Fit the desired accessory to the main body.
• Use the appliance in the surface you desire to vacuum.
USE
• Turn the appliance on, by using the on/off button (C).
• Select the desired speed with the speed selector button
(B), when this screen appears, it means:
- Low speed (3)
- High speed (4)
• This stick vacuum cleaner has an anti-block system:
- (7) When this screen appears, it means that the roller
brush is blocked and may be entangled with hair,
etc., and cannot rotate normally. Need to clean up the
objects of the floor brush
- (6) When this screen appears, it means dust tank is
full. Clear the garbage and clean the filter materials in
the dust cup
- (5) When this screen appears, it means over
temperature of battery: the temperature should not
exceed 75, and it will be reused after cooling at normal
room temperature.
- (8) When this screen appears, it means misuse of the
charger, indicates that it cannot be charged.
FITTING AN ACCESSORY
• The hand vacuum is designed in such a way that it
allows the following accessories to be fitted. Use the
combination that best meets your requirements. (Fig.1)
NOTE: Accessories can be fitted on the main body or on
the tube.
• 2 in 1 brush: Equipped with a brush at the end, which
brushes the surface as it is used.
• 2 in 1 Crevice nozzle: Specially designed for getting into
cracks and difficult corners.
• Mini turbo brush (**): Specially designed to remove
areas with pet hair, mites, or hard fabrics. (Sofa, mattress,
etc.)
• All-road roller brush: Specially desinged for hard floors
and carpets.
• Fuzzy roller brush (*): Specially desinged for delicate
floors like parquet.
ONCE YOU HAVE FINISHED USING THE APPLIANCE
• Turn the appliance off using the on/off button.
• Remove the battery from the appliance if you are not
intending to use the appliance during an extended period.
• Clean the appliance.
