Function overview
Torch body Building up an electrical potential between the weld metal and the workpiece
causes the uniform melting of the wire electrode at the welding location.
-
-
-
-
-
Hosepack Flexible connection between the torch neck and the wire-feed unit containing all
the lines needed to perform welding.
Coaxial cable Coaxial cables are used by Fronius exclusively in gas-cooled hosepacks. The co-
axial, symmetrical structure of the power cable and the control line around the
wirefeeding hose is particularly compact.
FSC - Fronius
The FSC is a compact interface between the hosepack and the wirefeeder.
System Connec-
tor -
-
-
-
-
Guides the wire electrode to the welding location
Guarantees the optimum protective gas shield over the welding location
Guarantees optimum heat dissipation
Available as liquid-cooled or gas-cooled torch body in different power cate-
gories
Available as a 45° fixed torch body and as a 15°, 30°, 45° and 60° Multilock
torch body.
Change hosepacks quickly and easily without mistakes or tools
Process stability ensured by defined current transfer
All control signals are integrated in the central FSC
Additional inner liner clamping system and a gas-seal system on the wire
electrode
Central connector for all MIG/MAG welding applications
