Ronix 7112 Bedienungsanleitung Seite 18

CAUTION !
- Since excessive cutting may cause overload of the motor or difficulty
in controlling the tool, the depth of cut should not be more than 15mm at
a pass when cutting grooves. When you wish to cut grooves more than
15mm deep, make several passes with progressively deeper bit settings
dangerously.
- Do not tighten the collet nut without inserting a bit or install small
shank bits without using a collet sleeve. Either can lead to breakage of
the collet cone.
1- Insert the bit all the way into the collet cone. Press the shaft lock to
keep the shaft stationary and use the wrench to tighten the collet nut
securely. When using router bits with smaller shank diameter, first insert
the appropriate collet sleeve into the collet cone, then install the bit as
described above.
2- To remove the bit, follow the installation procedure in reverse
ADJUSTING THE MAIN DEPTH OF CUT
By turning the knob, the upper limit of the tool body can be adjusted.
When the tip of the bit is retracted more than required in relate to the
base plate surface, turn the knob to lower the upper limit.
|
16
Electric Router1850W
