7 Installation instructions

7.2 Building in

Preparing the hob
Fit the elbow supplied on the appliance's gas connection.
Only for France:
Cut opening in worktop
• Saw the opening in the worktop. This should be done very accurately (see building in
dimensions).
• If the woodtop is made of treated wood, then coat the sawn surfaces of the top with
sealing varnish, to prevent moisture causing the top to swell.
104
1/2" ISO 228 (straight)
1/2" ISO 10226-1 (conical)
Sealing ring
1/2" ISO 228 (straight)
1/2" ISO 228 (straight)
Sealing ring
