INSTRUCTIONS OF THE LIMY 51 CARD
Connections of the new magnetic hall effect "4 wires" limit switches NYOTA 115 EVO range
Magnetic
limit switch
sensor
NYOTA 115 EVO
motor 2
6
L5
L-sw.O. 2
63 62 61
Opening
Limit switch
2
split into two
L-sw.C. = Closing Limit Switch
L-sw.O. = Opening Limit Switch
!
If mounted on the left swap the green wire of the limit switch with the brown one.
INDICATION LEDs
L1 ON = relay energized, Closing limit switch not engaged with automation N° 1
L2 ON = relay energized, Opening limit switch not engaged with automation N° 1
L3 ON = board on voltage
L4 ON = relay energized, Closing limit switch not engaged with automation N° 2
L5 ON = relay energized, Opening limit switch not engaged with automation N° 2
LIMY 51
8530
Drwg. No.
Magnetic limit switch
NYOTA 115 EVO
motor 1
L3
4
L4
L-sw.C. 2 L-sw.O. 1
43 42 41 33 32 31
Closing
Limit switch
Limit switch
2
split
into two
Configuration for NYOTA 115 EVO mounted on the right.
Via Mantova, 177/A - 37053 Cerea (VR) Italy
Ph. +39 0442 330422
sensor
3
1
L2
Opening
1
split
into two
Fax +39 0442 331054
e-mail: info@fadini.net - www.fadini.net
ELPRO 37 / DS / FN
ELPRO 12 EVO
56 55
L1
24 Vac/dc
12 Vac/dc
L-sw.C. 1
13 12 11
Closing
Limit switch
1
split into
two
Code 7231L
Output
24 Vac
12 13
!
24 Vac/dc
Pic. 1
