Engel EDGE Device Bedienungsanleitung Seite 7

4. Connect the "Support" interface to the
computer
Attention: Deactivate your WiFi connection
before you open the configuration page.
Note: You will be assigned an IP address by DHCP.
5. Open the configuration page
Access the following URL
in your browser:
http://192.168.157.100
6. Follow the configuration steps in the wizard
Follow the 3 steps below
in the network wizard:
1. Select network set-up
2. Select network settings
3. Register the EDGE device with ENGEL and check the connection
Note: You received the required token on the customer portal.
12 | EN
7. Assigning equipment to the EDGE device
Switch to the e-connect customer portal.
1. Edit the IP addresses for your equipment in "Plant control"
(Management > Plant control).
2. Switch to "EDGE Device Management".
3. Switch to the EDGE device details page.
4. The "Selectable equipment" tab shows all equipment with a valid
IP address, which can be assigned to an EDGE device. Assign the
desired equipment to the current EDGE device.
Note: Repeat all or some of the steps described whenever the IP address
of a piece of equipment changes or if you want to assign additional
equipment to an EDGE device.
8. Connect LAN1 (optional)
Only necessary with network seperation
Machine network LAN1
M1 M2
EN | 13
