Dynacord D 12A Technische Informationen
Quicklinks
FEATURES:
.
Powered 2-Way Biamped
Light-Weight Cabinet
.
Digital Power Amplifiers
.
80° x 40° Constant-Q HF Horn
.
Neodymium ND2-16 HF Driver
Wir weisen ausdrücklich darauf hin, dass bei
gehängten Lautsprecherboxen die einschlägigen
Sicherheitsbestimmungen zu beachten sind. Es
muss unbedingt qualifizierte Fachberatung in
Anspruch genommen werden!
We expressly point out that the relevant safety
regulations must be observed for "flying"
loudspeaker systems. It is imperative that quali-
fied expert advice is sought.
Technische Informationen
Architects and engineers
specifications
D 12A
POWERED 2-WAY BIAMPED
CABINET
350 W + 150 W RMS
AMPLIFIER OUTPUT POWER
Specifications
TYPE / NAME
Order No.
Cabinet
Lo Amplifier Power RMS
Mid-High Amplifier Power RMS
SPL 2,83 V / 1m
1W / 8 Ohm
Max. SPL 1m
(measured 10% THD)
Frequency range ( -10dB )
Nominal Coverage Angle
(Horizontal x Vertical)
Crossover frequency
Component HIGH
Order No.
Component LOW
Order No.
Power Requirement:
Dimensions (WxHxD) mm
Net weight
Shipping weight
Enclosure material
Finish
Grille
Handles
Warranty
Optional Accessories
SH-D12 Dust-Cover for D12-3
F212 Monitor feet for D12-3
MB 112 Eyebolt-Set M8 for D12-3
MB 212 U-Mounting Bracket
MB 312 Horizontal Cluster Plate
MB 200UMH U-Bracket
TMA Tilt angle for MB200 UMH
RMA Rotatable Mounting Kit
TC-02 Truss clamp
D 12A
D113164
Powered Full-Range 2-Way
350 Watts
150 Watts
98 dB
129 dB
45 Hz - 20 kHz
80° x 40°
1.2 kHz
Electro-Voice ND2-16
D366 910
Electro-Voice DL12BFH
D358 288
110-130VAC, 50-60Hz, 220-240VAC,
50-60Hz 600Watts
430 x 586 x 321
17.5 kg
20.5 kg
Heavy Duty Polypropylene
Black
Powder coated steel, Acoustic foam
1
36 Month
D113046
D113040
D113041
D113042
D113043
D170183
D112815
D112807
D112808
Inhaltszusammenfassung für Dynacord D 12A
- Seite 1 Technische Informationen Architects and engineers specifications D 12A POWERED 2-WAY BIAMPED CABINET 350 W + 150 W RMS AMPLIFIER OUTPUT POWER FEATURES: Specifications TYPE / NAME D 12A Powered 2-Way Biamped Light-Weight Cabinet Order No. D113164 Cabinet Powered Full-Range 2-Way...
-
Seite 2: Beschreibung
The line-level input signal can be connected to the cabinet by means auch unter ungünstigen akustischen Umgebungsbedingungen. of an XLR plug or a standard phone plug. A second D 12A cabinet can Mit den EASE und Ulysses Datenfiles sind problemlos auch be daisy-chained via a regular XLR microphone cable. - Seite 3 This connector is connected in parallel to the input allowing the through connection of the input audio signal. POWER Netzschalter zum Ein- und Ausschalten der D 12A. Der Netzschalter ist beleuchtet, wenn er eingeschaltet ist. Falls dies nicht der Fall ist, überprüfen Sie den Netzanschluss und ob das Netzkabel richtig eingesteckt ist.
-
Seite 5: Optional Accessories
Abmessungen / Dimensions (in mm) Optional Accessories MB-200 UMH MB-200 UMH MB-200 UMH + RMA +TMA + TC-02 Bosch Communications Systems Americas–Headquarter Americas Europe, Africa & Middle-East Asia & Pacific Rim–Headquarter Asia Telex Communications, Inc. Headquarter EAME Singapore: Telex Communications (SEA) Pte Ltd EVI Audio GmbH 12000 Portland Ave South, 38C Jalan Pemimpin...
