2.3 Optional Accessories

0
The following accessories are available for purchase separately from your
authorized dealer:
MH-M80(Meter)
The digital Remote Meter displays system operating information, error indications.
Information is displayed on an OLED display. Additionally, 3 status LEDs provide
system status at a glance. The Meter can easily set the parameters of the controller.
The meter can be flush mounted in a wall or surface mounted using the mounting
frame (included). The MH-M80 is supplied with 3.3 ft (1.0 m) of cable (Can be
extended), a mounting frame, and mounting screws. The MH-M80 connects to the
RJ-45 port on the MPPT. The MH-M80
MH-S80(Meter)
The digital Remote Meter displays system operating information, error indications.
Information is displayed on an OLED display. The Meter can easily set the
parameters of the controller. The Meter can be connected to 4 controllers at most,
and the controllers of the same battery system can work in parallel. The meter can
be flush mounted in a wall or surface mounted using the mounting frame (included).
The MH-S80 is supplied with 3.3 ft (1.0 m) of cable (Can be extended), a mounting
frame, and mounting screws. The MH-S80 connects to the RJ-45 port on the MPPT.
The MH-S80
USB-RS485 Cable
The USB-RS485 cable converts the RJ45 electrical interface to a standard USB
interface which enables communication between the MPPT and a personal
computer (PC). The cable can be used for programming custom charging setpoints,
and for logging data in SolarMa
device.
BT-02
A modular wiring box that can be added to MPPT controller. The box acts as a
transmitter (Near field remote control), users can use the mobile app to control the
MPPT through bluetooth. The wi
Cloud-Box-M2
A modular wiring box that can be added to MPPT controller. The box acts as a
transmitter (Cloud remote control), users can use the mobile APP to control the
MPPT through internet. The wire box
