GUDE Systems Expert Power Control 8041 Serie Anleitung Seite 118

Spezifikationen
epc8045spRevEnergyReactiveRes
ettable
epc8045CPUSensorVsystem
epc8045CPUSensorVaux
epc8045CPUSensorVmain
epc8045CPUSensorTcpu
epc8045NTPTimeValid
epc8045NTPUnixTime
epc8045NTPLastValidTimestamp
epc8045RCMBInfoIndex
epc8045RCMBCurrentRMS
epc8045RCMBlCurrentDC
epc8045RCMBOutputRMS
epc8045RCMBOutputDC
epc8045RCMBModuleStatus
epc8045SensorIndex
epc8045TempSensor
epc8045HygroSensor
epc8045AirPressure
epc8045Dew Point
epc8045Dew PointDiff
epc8045ExtSensorName
epc8045ExtActiveInputs
epc8045ExtInputIndex
epc8045ExtInput
epc8045ExtInputName
epc8045ExtInputPortNum
epc8045ExtInputBlockIndex
Expert Power Control 8041/8045
.87.1.5.5.2.1.23.x
Resettable Reverse Reactive Energy counter.
.87.1.5.14.1.0
System Voltage on CPU Board
.87.1.5.14.2.0
Auxiliary Voltage on CPU Board
.87.1.5.14.3.0
Main Voltage on CPU Board
.87.1.5.14.4.0
Temperature on CPU Board
.87.1.5.15.1.0
Show if valid Time is received
.87.1.5.15.2.0
show received NTP time as unixtime (secs since 1 January 1970)
.87.1.5.15.3.0
show seconds since last valid NTP timestamp received
.87.1.5.16.1.1.x
Index of RCMB Info entries
.87.1.5.16.1.2.x
Actual Residual Current RMS on Pow er Channel. According Type B IEC
60755. Only visible on models that support this feature.
.87.1.5.16.1.3.x
Actual Residual Current DC on Pow er Channel. According Type B IEC
60755. Only visible on models that support this feature.
.87.1.5.16.1.4.x
show s the output S1 of the RCMB module
.87.1.5.16.1.5.x
show s the output S2 of the RCMB module
.87.1.5.16.1.6.x
RCMB Module Status Word
.87.1.6.1.1.1.x
None
.87.1.6.1.1.2.x
actual temperature
.87.1.6.1.1.3.x
actual humidity
.87.1.6.1.1.5.x
actual air pressure
.87.1.6.1.1.6.x
dew point for actual temperature and humidity
.87.1.6.1.1.7.x
difference betw een dew point and actual temperature (Temp -
Dew Point)
.87.1.6.1.1.32.x
A textual string containing name of a external Sensor
.87.1.6.2.1.0
Number of suppported Input Channels.
.87.1.6.2.2.1.1.x
None
.87.1.6.2.2.1.2.x
Input state of device
.87.1.6.2.2.1.32.x
A textual string containing name of the Input
.87.1.6.2.2.1.33.x
Number of external Sensor Port w hen value greater zero, else device
built-in Input.
.87.1.6.2.2.1.34.x
Either index of device built-in Input, or index of Input in external sensor.
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
INTEGER RO
Unsigned32 RO
Unsigned32 RO
Integer32 RO
Unsigned32 RO
Unsigned32 RO
INTEGER RO
INTEGER RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
OCTETS RW
Unsigned32 RO
Unsigned32 RO
INTEGER RO
OCTETS RW
Integer32 RO
Integer32 RO
© 2023 GUDE Systems GmbH
118
