Spezifikationen
epc8045ResidualCurrent
epc8045LineSensorName
epc8045OVPIndex
epc8045OVPStatus
epc8045spActivePow erChan
epc8045spPow erIndex
epc8045spChanStatus
epc8045spAbsEnergyActive
epc8045spPow erActive
epc8045spCurrent
epc8045spVoltage
epc8045spFrequency
epc8045spPow erFactor
epc8045spPangle
epc8045spPow erApparent
epc8045spPow erReactive
epc8045spAbsEnergyReactive
epc8045spAbsEnergyActiveReset
table
epc8045spAbsEnergyReactiveRe
settable
epc8045spResetTime
epc8045spForw EnergyActive
epc8045spForw EnergyReactive
epc8045spForw EnergyActiveRes
ettable
epc8045spForw EnergyReactiveR
esettable
epc8045spRevEnergyActive
epc8045spRevEnergyReactive
epc8045spRevEnergyActiveReset
table
117
Expert Power Control 8041/8045
Resettable Reverse Reactive Energy counter.
.87.1.5.1.2.1.24.x
Actual Residual Current on Pow er Channel. According Type A IEC
60755. Only visible on models that support this feature.
.87.1.5.1.2.1.100.x
A textual string containing name of a Line Sensor
.87.1.5.2.1.1.x
None
.87.1.5.2.1.2.x
show s the status of the built-in Overvoltage Protection
.87.1.5.5.1.0
Number of Single Port Pow er Channels. Value is zero on EPC 8220
series.
.87.1.5.5.2.1.1.x
Index of Single Port Pow er Channel entries. Indices 0-5 mean Ports A1
to A6, 6-11 are Ports B1 to B6.
.87.1.5.5.2.1.2.x
0 = data not active, 1 = data valid
.87.1.5.5.2.1.3.x
Absolute Active Energy counter.
.87.1.5.5.2.1.4.x
Active Pow er
.87.1.5.5.2.1.5.x
Actual Curent on Pow er Channel.
.87.1.5.5.2.1.6.x
Actual Voltage on Pow er Channel
.87.1.5.5.2.1.7.x
Frequency of Pow er Channel
.87.1.5.5.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.87.1.5.5.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.87.1.5.5.2.1.10.x
L Line Mean Apparent Pow er
.87.1.5.5.2.1.11.x
L Line Mean Reactive Pow er
.87.1.5.5.2.1.12.x
Absolute Reactive Energy counter.
.87.1.5.5.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.87.1.5.5.2.1.14.x
Resettable Absolute Reactive Energy counter.
.87.1.5.5.2.1.15.x
Time in seconds since last Energy Counter reset.
.87.1.5.5.2.1.16.x
Forw ard Active Energy counter.
.87.1.5.5.2.1.17.x
Forw ard Reactive Energy counter.
.87.1.5.5.2.1.18.x
Resettable Forw ard Active Energy counter.
.87.1.5.5.2.1.19.x
Resettable Forw ard Reactive Energy counter.
.87.1.5.5.2.1.20.x
Reverse Active Energy counter.
.87.1.5.5.2.1.21.x
Reverse Reactive Energy counter.
.87.1.5.5.2.1.22.x
Resettable Reverse Active Energy counter.
Unsigned32 RO
OCTETS RW
Integer32 RO
INTEGER RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
