GUDE Systems Expert Power Control 8041 Serie Anleitung Seite 116

Spezifikationen
epc8045PortStartupMode
epc8045PortStartupDelay
epc8045PortRepow erTime
epc8045PortResetDuration
epc8045Buzzer
epc8045ActivePow erChan
epc8045Pow erIndex
epc8045ChanStatus
epc8045AbsEnergyActive
epc8045Pow erActive
epc8045Current
epc8045Voltage
epc8045Frequency
epc8045Pow erFactor
epc8045Pangle
epc8045Pow erApparent
epc8045Pow erReactive
epc8045AbsEnergyReactive
epc8045AbsEnergyActiveResetta
ble
epc8045AbsEnergyReactiveReset
table
epc8045ResetTime
epc8045Forw EnergyActive
epc8045Forw EnergyReactive
epc8045Forw EnergyActiveResett
able
epc8045Forw EnergyReactiveRes
ettable
epc8045RevEnergyActive
epc8045RevEnergyReactive
epc8045RevEnergyActiveResetta
ble
epc8045RevEnergyReactiveResett
able
Expert Power Control 8041/8045
.87.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.87.1.3.1.2.1.6.x
Delay in sec for startup action
.87.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.87.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.87.1.3.10.0
turn Buzzer on and off
.87.1.5.1.1.0
Number of suppported Pow er Channels.
.87.1.5.1.2.1.1.x
Index of Pow er Channel entries
.87.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.87.1.5.1.2.1.3.x
Absolute Active Energy counter.
.87.1.5.1.2.1.4.x
Active Pow er
.87.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.87.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.87.1.5.1.2.1.7.x
Frequency of Pow er Channel
.87.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.87.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.87.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.87.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.87.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.87.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.87.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.87.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.87.1.5.1.2.1.16.x
Forw ard Active Energy counter.
.87.1.5.1.2.1.17.x
Forw ard Reactive Energy counter.
.87.1.5.1.2.1.18.x
Resettable Forw ard Active Energy counter.
.87.1.5.1.2.1.19.x
Resettable Forw ard Reactive Energy counter.
.87.1.5.1.2.1.20.x
Reverse Active Energy counter.
.87.1.5.1.2.1.21.x
Reverse Reactive Energy counter.
.87.1.5.1.2.1.22.x
Resettable Reverse Active Energy counter.
.87.1.5.1.2.1.23.x
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
